**Journal of Materials Science and Chemical Engineering**

Vol.06 No.04(2018), Article ID:83661,8 pages

10.4236/msce.2018.64006

Simulation of Particle Agglomeration in Turbulent Flow

Peiling Yan, Deshuai Sun^{*}, Yang Yu, Xiankun Shen, Yanfei Qi^{ }

College of Chemical Engineering, Qingdao University, Qingdao, China

Received: October 13, 2017; Accepted: April 5, 2018; Published: April 12, 2018

ABSTRACT

Turbulence agglomeration is an effective way to promote agglomeration of particles. The coupling of classic Eulerian-Eulerian two-fluid model with population balance model was used to simulate the agglomeration process. The simulation results show that turbulence agglomeration could reduce 56% of emission of fine particles less than 10 μm. Smallest particles less than 2 μm were easily be removed, while the removal values of particles with medium size was very low. The suitable spacing of vanes was benefit to remove the fine particles from gas flow. Small angle of the vanes could improve the removal of fine particles.

**Keywords:**

Fine Particles, Turbulence, Vane Spacing, Vane Angle

1. Introduction

In recent years, the prevention and controlling of fine particle pollutant have become the focus of the whole society. Due to the larger surface area of fine particles, they are easy to enrich the toxic heavy metals, acidic oxides, organic pollutants, bacteria and viruses in air. When they enter into the body by respiration, they can deposit in the lungs, and therefore harm seriously the cardiovascular system [1] [2].

The fine particles in air are mainly from the combustion of fossil fuels. They are difficult to be removed completely by conventional dust collector because of the small size [3]. Particle agglomeration technology is a potential method to improve the removal efficiency of fine particles using the conventional dust collector. Several external fields and some chemical agents were applied to make fine particles to “grow” into large particles agglomeration which can be filtered easily. The agglomeration methods mainly include acoustic agglomeration, chemical agglomeration, heat agglomeration, turbulence agglomeration, electric agglomeration, vapor phase change agglomeration and etc.

Turbulence agglomeration technology is wildly used in industry. The velocity gradient in flow can energy to promote the collision and agglomeration of fine particles with larger particles, which is a simple and low cost technology. At present, many scholars have carried out extensive experimental and theoretical research on turbulence technology. The agglomeration experiment of fly ash particles in turbulent flow introducing by gas jet found that increasing Reynolds number and velocity of the jet in the main air flow could improve the efficiency of particle removal [4]. And the removal efficiency of particle less than 1 μm is very high [4]. Fluent is a commercial CFD package widely used in the simulation of gas solid two phase flow. The results from simulation using CFD software indicated the increasing gas velocity could enhance the effect of turbulence on the particles and increase the collision probability in a turbulence condensers composed of Z-type turbulent vanes [5]. Zhang et al. changed the configuration of the turbulent element and found these elements should not be arranged too densely or too distantly [6].

Gas jet was introduced into the agglomeration room to form a local turbulence to help particle agglomeration [7] [8]. In order to strengthen the effect of turbulence, one vanes assembly were provided along the overall direction of flow. The aim of this paper was to investigate the effect of vane on fine particle agglomeration in turbulent flow using the numerical simulation method.

2. Mathematical Model

2.1. The 2D Model of Fine Particles Agglomeration Chamber

To obtain the effect of the gas jet on the fine particle agglomeration, an experiment-scale agglomeration chamber was setup according to our previous work [9]. The agglomeration chamber was a round, transparent pipe with an inner diameter of 50 mm and a length of 1000 mm. The two ends of the tube were sealed by plates. The vain assembly was fixed inside the chamber. The size of the vane is 15 × 15 mm, and the distance of vane was 100 mm. A round, jet nozzle, with an inner diameter of 2.0 mm, was located in the chamber wall at 150 mm below the main inlet nozzle. In simulation process, a 2D model was selected.

The physical model of the agglomeration chamber was meshed by unstructured grid in Fluent 15.0 pre-processing software Gambit, and the grid independence was verified. It was found that increasing the number of grids had little effect on the flow field in the agglomeration chamber. Therefore, the grids (68180) and the mesh sizes were considered to meet the requirements of the calculation accuracy. Figure 1 illustrated the chamber configuration and the CFD grid of partial enlargement.

2.2. Two-Phase Fluid Model

The classic Eulerian-Eulerian two-fluid model is used to simulate the agglomeration, which assumed that the continuous and dispersed phase are all continuous

Figure 1. Agglomeration chamber structure diagram and local grid diagram.

interpenetrating into and interacting with each other in the whole domain under consideration [10]. Momentum and continuity equations were solved for each phase. Due to the low centration of fine particles, standard k-ε model was selected to calculate two-phase flow [11].

2.3. Population Balance Model

In order to improve the accuracy, this paper introduces the population balance model based on Euler two fluid model (PBM), to calculate the particle movement and the distribution of polydisperse particles [12]. Therefore the population balance concept is a well-established method to calculate the size distribution of the dispersed phase. In the process of turbulence agglomeration, PBM is used to describe the variation of particles numbers, which assumes that the new agglomerations generate after the collision between particles. The PBM equation can be expressed as follow.

$\frac{\partial}{\partial t}[n(v,t)]=\frac{1}{2}{\displaystyle {\int}_{0}^{v}\alpha (v-v\text{'},v\text{'})}n(v-v\text{'},t)n(v\text{'},t)dv\text{'}-{\displaystyle {\int}_{0}^{\infty}\alpha (v,v\text{'})}n(v,t)n(v\text{'},t)dv\text{'}$ (1)

where $\partial [n(v,t)]$ is the number concentration in the volume interval $v$ to $v+dv$ at time $t$ . $a(v,v\text{'})$ is the aggregation kernel between two particle with volumes of $v$ and $v\text{'}$ . $n(v,t)$ is the size distribution function. The PBM equation is an integral equation solved by the means of discrete method in this paper [13].

2.4. Turbulent Aggregation Kernel

Turbulent aggregation kernel is an important parameter related to Stokes number (S_{t}). According to S_{t} value, particles can be divided to three kinds: zero inertial particles (S_{t}~0), finite inertial particles and great inertial particles (S_{t}~∞). These particles were influenced by different flow forces, which results in the different turbulent aggregation kernel as Equation (2) to Equation (4).

$\alpha \left({d}_{i},{d}_{j}\right)={\zeta}_{T}\sqrt{\frac{8\pi \epsilon}{15v}}\frac{{\left({d}_{i}+{d}_{j}\right)}^{3}}{8}$ (2)

$\alpha \left({d}_{i},{d}_{j}\right)=\frac{{\left({d}_{i}+{d}_{j}\right)}^{3}}{8}\sqrt{\frac{8\pi \epsilon}{15\nu}}\times {c}_{0}{\left(\frac{2\eta}{{d}_{i}+{d}_{j}}\right)}^{0.08+0.897{s}_{t}}$ (3)

$\alpha \left({d}_{i},{d}_{j}\right)={\zeta}_{T}{2}^{3/2}\sqrt{\pi}\frac{{\left({d}_{i}+{d}_{j}\right)}^{2}}{4}\times \sqrt{\left({U}_{i}^{2}+{U}_{j}^{2}\right)}\text{}$ (4)

where d_{i}, d_{j} is the diameter of particle
$i$
and
$j$
, respectively. ζ_{T} is a pre-factor that takes into account the capture efficiency coefficient of turbulent collision. εis the shear rate. η was turbulence length scale. U_{i} is the mean squared velocity for particle
$i$
[14].

2.5. Simulation Conditions

The aerosol inlet boundary is velocity condition inlet, in which the velocity of main gas was 0.8 m/s. And the outlet boundary was pressure condition. The particle density was 1838 kg/m^{3}, and the initial particle fraction was 0.03%. The velocity of gas jet was 22 m/s. The simulation solution was solved using Phase Coupled SIMPLE. The initial particle size was in range of 0.43 - 17 μm, which was divided into nine intervals, as shown in Table 1.

3. Results and Discussions

3.1. Effect of Turbulent Agglomeration

When the gas containing fine particles flowed across the vanes, the small scale turbulence around the vane entrained the smaller particles, and then increased the retention time. Therefore, they could be captured easily by larger particles, resulting inthe decrement of the number of fine particle. Figure 2 described the cumulative number distribution of the particles. From Figure 2(a), it was found 88% of particles was less than 2 μm (PM2) for the initial distribution, although the mass of these particles was very small. After agglomeration of particles, the number of these smaller particles decreased to 45%. For particles with the diameter less than 10 μm (PM10), agglomeration could reduce 41% of emission [9]. Figure 2(b) showed the simulation results, and suggested the percent of PM10 decreased about 56%. The simulated data were slightly higher than the experimental value.

Figure 3 shows the size distribution of the particles and removal efficiency after agglomeration. It could be seen from Figure 3(a) that the peak diameters of fine particles were 2.73 μm and 10.88 μm. After agglomeration, the volume fraction for all particles decreased, especially for the particles with peak diameter. Figure 3(b) showed the removal efficiency of particles. The removal values of

Table 1. Initial particle diameter distribution.

(a) (b)

Figure 2. Cumulative number of particles distribution.

(a) (b)

Figure 3. Effect of oblique vane on particle agglomeration.

particles less than 2 μm was the very high, while the value of 7 μm particles was only 20%. These results could be explained by the fact the smallest particles were easily entrained by small vortex of turbulence and collided with other particles. Therefore, these smallest particles grew quickly into particles with medium size. For 10 um-size particles, they were less susceptible to disturbance of the gas flow so that they were collided by small particles to form larger agglomeration, which resulted in higher removal efficiency.

Figure 4. Effect of vane interval on particle removal efficiency.

Figure 5. Effect of vane angle on particle removal efficiency dissipation rate.

Figure 6. Effect of vane angle on turbulent.

3.2. Effect of Vanespacing on Particle Agglomeration

The spacing of vanes could affect the vortex of the turbulent flow. Figure 4 gave the effect of vane spacing on the number removal efficiency. When the spacing of vanes was 50 mm and 100 mm, the removal efficiency of particles with all size were up to the best values. Subsequently, the removal value decreased with the increment of the spacing of vane. The suitable spacing of vanes was benefit to form the contiguous vortex of the turbulent flow, which could entrain continuously the small particles. The excessive spacing could harm the continuity of the structure of vortex, which decreased the agglomeration of particles in turbulent flow [6].

3.3. Effect of Vane Angle on Particle Agglomeration

Figure 5 showed the effect of vane angles on the removal efficiency of particle. The removal efficiency of the particles decreased with increasing the angle of vanes. For the lowest efficiency at 7 μm, the values decreased from 32% to 13%. This indicated the vane angle affected obviously the strength of turbulent flow, as shown in Figure 6.

Figure 6 revealed the turbulence dissipationrate at the cross section of Y = 580 mm. It can be seen the turbulence dissipation rate decreased with the increment of the vane angles. There were two maximum peaks when the vane angles was in range of 0˚ - 30˚, suggesting the best entrainment of fine particles. Therefore, the higher removal efficiency could be observed. This result was consistent with the reports of Zhang et al. [6].

4. Conclusions

1) For fine particles from fly ash, 88% of particles was less than 2 μm according to the cumulative number distribution. Turbulence could encourage the agglomeration of fine particles. After agglomeration of particles, the number concentration of PM 10 could reduce 41% of emission according to experimental data. The simulation data indicated the percent of PM 10 decreased about 56%. Smallest particles less than 2 μm were easily be removed, while the removal values of particles with medium size was very low.

2) The suitable spacing of vanes was benefit to remove the fine particles from gas flow. When the spacing of vanes was 50 mm and 100 mm, the removal efficiency of particles with all size were up to the maximum values. Small angle of the vanes could improve the removal of fine particles.

Acknowledgements

The authors wish to acknowledge financial support from National Natural Science Foundation of China (No. 21206080), from Major Project of Shandong Province for Research and Development (No. 2015GSF117026) and from Natural Science Foundation of Shandong Province (No. ZR2017MB024).

Cite this paper

Yan, P.L., Sun, D.S., Yu, Y., Shen, X.K. and Qi, Y.F. (2018) Simulation of Particle Agglomeration in Turbulent Flow. Journal of Materials Science and Chemical Engineering, 6, 39-46. https://doi.org/10.4236/msce.2018.64006
