Energy and Power Engineering, 2013, 5, 728-732 doi:10.4236/epe.2013.54B141 Published Online July 2013 (http://www.scirp.org/journal/epe) Multi-level Evaluation of Load Supply Adequacy for Transmission Network Zheng-lin Yang, jian-guo Yao, jian Geng China Electric Power Research Institute, Nanjing, China Email: yangzhenglin@epri.sgcc.com.cn, yaojianguo@epri.sgcc.com.cn, gengjian@epri.sgcc.com.cn Received March, 2013 ABSTRACT Considering sharp increase of central integration scale of intermittent energy generation, power system couldn’t rely on the determined model based operation schedule to assure its reliable load supply. Then, this article presents a new load supply adequacy evaluation method, which based on continuous security constrained generation optimization, and pro- vides the functional architecture design of online multi-level short term load supply adequacy evaluation system. Keywords: Load Supply Adequacy; Operation Schedule; Security Analysis; Continuous Security Constrained Generation Optimization; Unit Commitment; Economic Dispatch 1. Introduction It is the main objective of short term operation schedule to secure power system operation, improve load supply reliability and optimize generation resource configuration. Outage schedule, one type of operation schedule, should provide enough margins for reliable power system opera- tion by optimizing transmission network topology. Gen- eration schedule, another type of operation schedule, should optimize multi-periods unit commitment status and output according to predefined objective, taking con- sideration of power supply balance, transmission capa- bility constraints and generation operation constraints. In traditional deterministic model for short term operation schedule optimization, outage schedule and generation schedule are optimized on the assumption that all genera- tion units meet certain reliability level in operation, and the negative influence of load forecast bias and forced outage of transmission and generation device could be avoided by scheduled regulation reserve and spinning reserve. With integration of large scale intermittent energy generation, such as hydropower, wind power and photo- voltaic power, its negative influence on operation has far exceeded load forecast bias. The traditional generation schedule optimization model, which treat intermittent energy power as fixed generation and eliminate it from system load according to forecast of hydropower, wind power and photovoltaic power, could not cope with the random fluctuation introduced by large scale intermittent energy generation. It is important to arrange enough margins in outage schedule optimization to meet addi- tional reserve requirement caused by intermittent energy generation. Therefore, it is of great value for improving load supply reliability to accurately evaluate maximized load supply capability for transmission network. Paper [1] presented load supply adequacy index for bus, which is defined as the ratio of maximized load supply capability to current bus load, and applied in load supply capability evaluation of buses. It is the main objective of outage schedule optimization and evaluation to arrange enough available generation capacity and transmission capacity for coming generation optimization in order to cope with fluctuation of load. This article applies load supply ade- quacy index in multi-level evaluation of load supply ca- pability on every bus according to outage schedule. Load supply adequacy evaluation could provide quantitative margin information to assist operator evaluating the adaptability of power system for load fluctuation. Through the evaluation of load supply adequacy index, the transmission network planner and operator could evaluate the quantitative security margin of transmission network on the basis of qualitative security [2] evaluation of operation schedule, and also could evaluate the adap- tability for integration of intermittent energy generation. In the reference documents, load supply adequacy in- dex of every bus is evaluated by increasing load continu- ally under the assumption that all other bus load remain- ing unchanged. The unreasonable assumption restricts its application in engineering. Firstly, there is strong rela- tionship between bus loads variation. Secondly, it is too conservative to evaluate load supply adequacy index by increasing generation at equivalent ratio to meet bus load growth. Hence, this article presents multi-level load sup- Copyright © 2013 SciRes. EPE Z.-L. YANG ET AL. 729 ply adequacy evaluation method, which evaluates load supply adequacy from bus, zone and system level, and integrates sensitivity factor based evaluation method and continuous security constrained generation optimization based evaluation method[3-8] to make the index more accurate reflect load supply adequacy of transmission network. Based on multi-level load supply adequacy evaluation, the online short term load supply adequacy evaluation system is designed and implemented. 2. Theory of Load Supply Adequacy Evaluation 2.1. Sensitivity Factor Based Evaluation Method Paper 1 presents bus load supply adequacy index and sensitivity factor based evaluation method for the first time. The theory is as follows. First of all, ij , the sensitivity of load j on branch i, is calculated. Then, the maximized load supply capability ,max on bus j is calculated considering available transmission capability of branch i by increasing genera- tion output by equivalent ratio and assuring balance be- tween generation and load. Considering all branch, the minimized sens Pij j, max1j, max2j, maxij, max PminP,P P is defined as load supply capability of bus j and j is defined as load supply adequacy of bus j. i,max i ij, maxj ij ff P-P sens (2.1) j, max j j P P (2.2) i,max represents thermal limit of branch i, represents the power flow of branch i at initial state, ij, max repre- sents the maximized available load supply capability of bus load j considering the transmission constraint of branch i. fi f P ij Indicates the relationship between branch i and load j, larger ij represents stronger relationship be- tween them. The difference between ,max and sens sens fi j f represents the available transmission capability of branch i considering its thermal limit. The smaller difference between ,max and fi j f , indicates the smaller load sup- ply adequacy j of load j, which has strong relationship with branch i. Considering thermal limit of branch and its relation- ship between bus load, sensitivity factor based evaluation method evaluates the load supply adequacy by selecting the minimized load supply capability among all the maximized load supply capability considering thermal limit constraints of all branches. In sensitivity factor based evaluation process, not only thermal limit of branch, but also the transient limit of interface and limi- tation of generation capability has great influence on load supply adequacy of bus load. Sensitivity factor based evaluation method has two shortcomings in engineering application. Firstly, it is only suitable for single bus load supply adequacy evalua- tion. Secondly, it is more conservative since it rely on proportional generation growth other than consider more rational generation output and unit commitment. 2.2. Continuous Security Constrained Generation Optimization Based Evaluation Method The theory of continuous security constrained generation optimization based method is to calculate the maximized load supply capability through continuous load growth and corresponding generation optimization to find feasi- ble generation schedule, which could satisfy all the pow- er balance constraints, transmission security constraints and generation security operation constraints. The evalu- ation process of continuous security constrained genera- tion optimization based method is demonstrated as Fig- ure 1. Ld0 represents initial load of evaluation object, and the growth ratio of each round is δ. The first round evalua- tion starts after the setting of objective and constraint model for generation optimization. In every round, base Figure 1. Diagram of continuous security constrained gen- eration optimization based evaluation method. Copyright © 2013 SciRes. EPE Z.-L. YANG ET AL. 730 case security analysis and contingency analysis should be carried out on achieved feasible generation schedule after generation optimization. And if any new violated trans- mission devices are detected, the new violations should be sent to generation optimization engine as additional transmission security constraints until no other violations appear. Then increase the load by & and move to next round evaluation. On the other hand, if generation opti- mization engine could not find feasible generation sche- dule that satisfy all constraints, the constraints are re- laxed and the ld of last round should be taken as the maximized load supply capability, and should be load supply adequacy of evaluation object. Then the evaluation process ends. Since evaluation load grows and security constrained generation optimization run every round, it is called continuous security constrained gen- eration optimization based evaluation method. /0Ld ld In generation optimization model, the constraints can be divided into system power balance, generation opera- tion and transmission security. For unit commitment, the constraints include system power balance, minimized regulation reserve, maximized unit output, minimized unit output, ramp up and ramp down speed, initial unit status, minimized run time, minimized offline time, unit regulation reserve, must run, fixed unit commitment or output schedule for generation, transmission capability in base case and contingency analysis, and also include the maximized output, minimized out, maximized energy, minimized energy, minimized regulation reserve and spinning reserve for a group of generations. Any generation schedule, which satisfy all the con- straints listed above for certain load level, is feasible for load supply adequacy evaluation, which has no specific requirement on optimization objective. According to available cost model of generation, the optimization ob- jective could be one of minimized energy cost, mini- mized fuel cost or minimized bias of yearly energy con- tract accomplishment between generation providers. Maximized transmission margin could also be taken as optimization objective by converting from load ratio of transmission device into virtual dispatch cost. Maximized transmission margin optimization could achieve the best performance with moving of transmission capability constraints to optimization objective model. Compared with sensitivity factor based evaluation method, continuous security constrained generation op- timization based evaluation method not only could be used for single period load supply adequacy evaluation, but also could be used for accurate multi-period coupled evaluation, and the evaluation result could be more rea- sonable. For single period evaluation, the ramp speed of generation need not be considered in generation optimi- zation. But for multi-period evaluation, all the constraints listed above should be taken into consideration for con- tinuous load growth. Considering high strength optimiza- tion, the calculation of continuous security constrained generation optimization based evaluation method need more time than sensitivity factor based evaluation me- thod. 3. Multi-level Load Supply Adequacy Eval- uation of Transmission Network 3.1. Level of Short Term Load Supply Adequacy Evaluation The level of short term load supply adequacy evaluation could be divided into bus, zone and system. Bus level evaluation takes single bus load as evaluation object, calculates maximized load supply capability of bus con- sidering continuous load growth and assumption of any other bus load remaining unchanged. For the strength relationship between bus loads, the situation that one bus load grows continuously and all other remain unchanged seldom appears. The result of bus load level evaluation could not reflect load supply adequacy of transmission network intuitively and is inconvenient to apply in engi- neering. Power system operator care more about the load growth margin of a zone or even all the system than bus level. Power system operator not only care load supply adequacy of one period, but also care the load supply adequacy of all periods of a day to evaluate the maxi- mized margin of load supply for random fluctuation of all kinds such as cased by intermittent energy resource. Zone level evaluation takes single zone as evaluation object, calculates maximized load supply capability of zone considering continuous load growth and assumption of any other zone load remaining unchanged. According to evaluation time scope, zone level evaluation could be divided into single period and multi-periods evaluation. System level evaluation takes all the system as evalua- tion object, calculates maximized load supply capability of system considering continuous system load growth and assumption of tie line exchange remaining un- changed. System level evaluation also could be divided into single period and multi-periods evaluation. 3.2. Load Growth Model In order to reduce the evaluation times, this article sets 2 as the maximized evaluable load supply adequacy limit and should stop evaluating if current index has already exceeded the limit. According to the limit setting of load supply adequacy index, this article adopts dichotomy method to determine load growth of next round. In order to reflect the relativity of load growth among bus load in zone level and system level load supply ade- quacy evaluation, the growth of load should be allocated to every bus load by rational proportion, which assures evaluation result could reflect the load supply capability Copyright © 2013 SciRes. EPE Z.-L. YANG ET AL. 731 in future operation. General growth modes of bus load are listed as follows. 1) Proportional growth All bus loads grow proportionally. This mode is suit- able when the bus load is same in type and has same va- riety rule, or has no scrutiny load model. 2) Proportional growth by load group Separating bus load into several group by load type, bus loads in same group apply the same growth ratio, and every group could have different growth ratio. This mode is suitable when every type load has different variety rule or integration of intermittent energy generation centrally. 3) Proportional growth by load type As for zone or system which has scrutiny load model for every bus load, the bus load could be divided into group logically by load type. Then, appropriate growth ratio is selected for every load type to simulate load vari- ation of zone or system. For multi-period evaluation, the same load growth mode applies for every period generally. 3.3. Zone Level Load Supply Adequacy Evaluation For zone level short term load supply adequacy evalua- tion in every round, the total load growth is allocated to every bus according to selected load growth mode and load of other zone remaining unchanged. Then optimize unit commitment and output with continuous security constrained generation optimization based evaluation method to satisfy all the constraints. If feasible genera- tion schedule is achieved, then increase load and move to next round evaluation. Otherwise terminate evaluation process and select load supply adequacy index of last round as result for evaluated zone. As for same load growth ratio in every period, the load supply adequacy of every period is same. Repeating above evaluation process for every zone, the load supply adequacy index of every zone could be achieved. 3.4. System Level Load Supply Adequacy Evalu- ation For system level short term load supply adequacy evalu- ation in every round, the system load growth is allocated to every bus according to selected load growth mode and keeping tie line exchange fixed. Then optimize unit commitment and output with continuous security con- strained generation optimization based evaluation me- thod to satisfy all the constraints. If feasible generation schedule is achieved, then increase load and move to next round evaluation. Otherwise terminate evaluation process and select load supply adequacy index of last round as result for evaluated system. As for same load growth ratio in every period, the load supply adequacy of every period is same. 4. Design of Online Multi-level Short Term Load Supply Adequacy Evaluation System The functional infrastructure of online short term load adequacy evaluation system is demonstrated as Figure 2, the main functions are data management, bus level evaluation, zone level evaluation, system level evaluation, sensitivity factor based evaluation, continuous security constrained generation optimization based evaluation and parameter management. The continuous generation op- timization based evaluation module is composed of gen- eration optimization and security analysis. Data management module serves for model and opera- tion data input, which include network model, outage schedule of generation and transmission devices, trans- mission capability, system load forecast, bus load fore- cast, from operation schedule application to form base case for evaluation. Bus level evaluation module imple- ments evaluation data preparation, calling of sensitivity factor based evaluation service , continuous security con- strained generation optimization based evaluation service and demonstration of evaluation result. Zone level Figure 2. Functional infrastructure of online multi-level short term load supply adequacy evaluation system. Copyright © 2013 SciRes. EPE Z.-L. YANG ET AL. Copyright © 2013 SciRes. EPE 732 evaluation module implements load growth management of zones, calling of continuous generation optimization based evaluation service and demonstration of evaluation result of every zone. System level evaluation module implements load growth management of system, calling of continuous generation optimization based evaluation service and demonstration of evaluation result of system. Sensitivity factor based evaluation module provides sen- sitivity calculation service and sensitivity factor based load supply adequacy evaluation service. Continuous security constrained generation optimization module provides multi-objective, security constrained unit com- mitment and economic dispatch service, provides single period and multi-periods coupled load supply adequacy evaluation service and calling of base case power flow analysis, contingency analysis and sensitivity calculation service provided by security analysis module automati- cally. Parameter management module implements load growth mode management, objective model and con- straint model management for generation optimization, and parameter management for security analysis. Visu- alization of load supply adequacy module demonstrates load supply adequacy distribution of transmission net- work by contour and three dimensional bar methods. Continuous security constrained generation optimiza- tion based evaluation method not only could apply for single period and multi-periods zone level evaluation and system level evaluation for large scale transmission net- work, but also could apply for bus level evaluation for small scale transmission network. As for enormous cal- culation of bus level evaluation, only sensitivity factor based evaluation method could be use for online evalua- tion in engineering for large scale transmission network. For example of provincial power grid with 700 calcu- lating node, the evaluation time of 96 periods system level evaluation is about 8 minutes, and the evaluation time of 96 periods zone level is about 5 minutes by one ThinkPad computer equipped with 256G hard disk and 6G memory. The performance could meet the require- ment of online application in engineer. 5. Conclusions This article presents multi-level, including bus level, zone level and system level, load supply adequacy evalu- ation method, which is able to evaluate load supply ade- quacy of transmission network at any operation status and provide reliable technical support for coping with random fluctuation caused by intermittent energy genera- tion. After analysis of sensitivity factor based evaluation method, it presents a high performance continuous secu- rity constrained generation optimization based evaluation method, which is more feasible in engineering applica- tion for zone level and system level load supply ade- quacy evaluation. And provide the functional design of online multi-level short term load supply adequacy evaluation system, which could be integrated into opera- tion schedule applications. Though the evaluation fo- cuses on load growth mode analysis, same theory could be used in load decreasing analysis so as to cope with the influence of bidirectional fluctuation of large scale in- termittent energy generation. REFERENCES [1] L. R. Xie, Z. L. Yang, C. Zhang and J. F. Huan, “Security Evaluation of Maintenance Schedule Based on Load Sup- ply Adequacy and Generation Loss,” Power System Automation Conference, 2010. [2] Z. Q. Ge, D. X. Wang and M. H. Ge, “Security Checking System for Daily Generation Scheduling of East China Power Grid and Its Expansion,” Automation of Electric Power Systems, Vol. 32, No. 10, 2008, pp. 45-48. [3] Z. X. Chen, K. Xie and J. Zhang, “Optimal Model and Algorithm for Day-ahead Generation Scheduling of Transmission Grid Security Constrained Convention Dispatch,” Automation of Electric Power Systems, 2009, Vol. 33, No. 1, pp. 10-13. [4] J. Geng Jian, F. Xu Fan and J. G. YAO, “Performance Analysis of Mixed-integer Programming Based Algo- rithm for Security Constrained Unit Commitment,” Automation of Electric Power Systems, Vol. 33, No. 21, 2009, pp. 24-27, [5] N. Zhang, H. K. Chen, X. M. Luo, et al., “Model and Algorithm of Energy-conservation Based Generation Dis- patching for Guangdong Power Grid,” Power system Technology, Vol. 32, No. 24, 2008, pp. 11-15. [6] X. L. Li, J. Y. Zhou and Y. Erkeng, “Linear Mixed Inte- ger Programming Algorithm for Unit Commitment Based on Dynamic Search,” Automation of Electric Power Sys- tems, Vol. 32, No. 21, 2008, pp. 18-21. [7] G. W. Chang, M. Aganagic, J. G. Waight, J. Medina, T. Burton, S. Reeves and M. Christoforidis, “Experiences with Mixed Integer Linear Programming Based Ap- proaches on Short-term Hydro Scheduling,” IEEE Trans- actions Power Syst, Vol. 16, No. 4, 2001, pp. 743-749. [8] Z. L. Yang, G. Q. Tang and L. L. Li, “Application of Relaxed Constraints Model on Generation Schedule Optimization,” Automation of Electric Power Systems, Vol. 34, No. 14, 2010, pp. 53-57, |
