Journal of Software Engineering and Applications, 2013, 6, 36-46 http://dx.doi.org/10.4236/jsea.2013.610A005 Published Online October 2013 (http://www.scirp.org/journal/jsea) Traceability in Acceptance Testing Jean-Pierre Corriveau1, Wei Shi2 1School of Computer Science, Carleton University, Ottawa, Canada; 2Business and Information Technology, University of Ontario Institute of Technology, Oshawa, Canada. Email: jeanpier@scs.carleton.ca, wei.shi@uoit.ca Received August 30th, 2013; revised September 28th, 2013; accepted October 6th, 2013 Copyright © 2013 Jean-Pierre Corriveau, Wei Shi. This is an open access article distributed under the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. ABSTRACT Regardless of which (model-centric or code-centric) development process is adopted, industrial software production ultimately and necessarily requires the delivery of an executable implementation. It is generally accepted that the qual- ity of such an implementation is of utmost importance. Yet current verification techniques, including software testing, remain problematic. In this paper, we focus on acceptance testing, that is, on the validation of the actual behavior of the implementation under test against the requirements of stakeholder(s). This task must be as objective and automated as possible. Our first goal is to review existing code-based and model-based tools for testing in light of what such an ob- jective and automated approach to acceptance testing entails. Our contention is that the difficulties we identify originate mainly in a lack of traceability between a testable model of the requirements of the stakeholder(s) and the test cases used to validate these requirements. We then investigate whether such traceability is addressed in other relevant speci- fication-based approaches. Keywords: Validation; Acceptance Testing; Model-Based Testing; Traceability; Scenario Models 1. Introduction The use and role of models in the production of software systems vary considerably across industry. Whereas some development processes rely extensively on a diversity of semantic-rich UML models [1], proponents of Agile methods instead minimize [2], if not essentially eliminate [3] the need for models. However, regardless of which model-centric or code-centric development process is adopted, industrial software production ultimately and necessarily requires the delivery of an executable imple- mentation. Furthermore, it is generally accepted that the quality of such an implementation is of utmost impor- tance [4]. That is, except for the few who adopt “hit- and-run” software production1, the importance of soft- ware verification within the software development life- cycle is widely acknowledged. Yet, despite recent ad- vancements in program verification, automatic debug- ging, assertion deduction and model-based testing (here- after MBT), Ralph Johnson [5] and many others still view software verification as a “catastrophic computer science failure”. Indeed, the recent CISQ initiative [6] proceeds from such remarks and similar ones such as: “The current quality of IT application software exposes businesses and government agencies to unacceptable levels of risk and loss.” [Ibid]. In summary, software verification remains problematic [4]. In particular, soft- ware testing, that is evaluating software by observing its executions on actual valued inputs [7], is “a widespread validation approach in industry, but it is still largely ad hoc, expensive, and unpredictably effective” [8]. Gri- eskamp [9], the main architect of Microsoft’s MBT tool Spec Explorer [10], indeed confirms that current testing practices “are not only laborious and expensive but often unsystematic, lacking an engineering methodology and discipline and adequate tool support”. In this paper, we focus on one specific aspect of soft- ware testing, namely the validation [11] of the actual behavior of an implementation under test (hereafter IUT) against the requirements of stakeholder(s) of that system. This task, which Bertolino refers to as “acceptance test- ing” [8], must be as objective and automated as possible [12]: errors originating in requirements have catastrophic economic consequences, as demonstrated by Jones and Bonsignour [4]. Our goal here is to survey existing tools for testing in light of what such an “objective and auto- mated” approach to acceptance testing entails. To do so, we first discuss in Section 2 existing code-based and, in 1According to which one develops and releases quickly in order to grab a market share, with little consideration for quality assurance and no commitment to maintenance and customer satisfaction! Copyright © 2013 SciRes. JSEA Traceability in Accept an ce Testing 37 Section 3, existing model-based approaches to accep- tance testing. We contend that the current challenges inherent to acceptance testin g originate first and foremost in a lack of traceability between a testable model of the requirements of the stakeholder(s) and the test cases (i.e., code artifacts) used to validate the IUT against these re- quirements. We then investigate whether such traceabil- ity is addressed in other relevant specification-based ap- proaches. Jones and Bonsignour [4] sugg est th at the validation of both functional and non-functional requirements can be decomposed into two steps: requirements analysis and requirements verification. They emphasize the impor- tance of requirements an alysis in order to obtain a speci- fication (i.e., a model) of a system’s requirements in which defects (e.g., incompleteness and inconsistency) have been minimized. Then requirements verification checks that a product, service, or system (or portion thereof) meets a set of design requirements captured in a specification. In this paper, we only consider functional requirements and, following Jones and Bonsignour, pos- tulate that requirements analysis is indeed a crucial first step for acceptance testing (without reviewing however the large body of literature that pertains to this task ). We start by addressing code-based approaches to acceptance testing because they in fact reject this postulate. 2. Code-Based Acceptance Testing? Testing constitutes one of the most expensive aspects of software development and software is often not tested as thoroughly as it should be [8,9,11,13]. As mentioned earlier, one possible standpoint is to view current ap- proaches to testing as belonging to one of two categories: code-centric and model-centric. In this section, we brief- ly discuss the first of these two categories. A code-centric approach, such as Test-Driven Design (TDD) [3] proceeds from the viewpoint that, for “true agility”, the design must be expressed once and only once, in code. In other words, there is no requirements model per se (that is, a specification of the requirements of a system captured separately from code). Conse- quently, there is no traceability [14] between a require- ments model and the test cases exercising the code. But, in our opinion, such traceability is an essential facet of acceptance testing: without traceability of a suite of test cases “back to” an explicitly-captured requirements mo- del, there is no objective way of measuring how much of this requirements model is covered [11 ] by this test suite. Let us consider, for illustration, the game of Yahtzee2 (involving throwing 5 dice up to three times per round, holding some dice between each throw, to achieve the highest possible score according to a specific poker-like scoring algorithm). In an assignment given to more than a hundred students over several offerings of a 4th year undergraduate course in Software Quality Assurance at Carleton, students were first asked to develop a simple text-based implementation of this game using TDD. De- spite familiarity with the game and widesp read availabil- ity of the rules, it is most tellin g that only a few students had their implementation preven t the holding of all 5 dice for the second or third roll... The point to be grasped is that requirement analysis (which does not exist in TDD for it would require the production of a specification) would likely avoid this omission by checking the com- pleteness of the requirements pertaining to holding dice. A further difficulty with TDD and similar approaches is that tests cases (in contrast to more abstract tests [11]) are code artifacts that are implementation-driven and implementation-specific. For example, returning to our Yahtzee experiment, we observed that, even for such a small and quite simple application, the implementations of the students shared similar designs but vastly differed at the code level. Consequen tly, the test suites of students also vastly differed in their code. For example, some students handled the holding of dice through parameters of the procedure responsible for a single roll, some used a separate procedure, some created a data structure for the value and the hold value of each die, and some adopted much less intuitive approaches (e.g., involving the use of complex return values...) resulting in rather “obscure” test cases. In a follow-up assignment (before the TDD assignment was returned and students could see which tests they had missed), students were asked to de- velop a suite of implementation-independent tests (writ- ten in English) for the game. Students were told to refer to the “official” rules of the game to verify both consis- tency and completeness as much as they could (that is, without developing a more formal specification that would lend itself to a systematic method for verifying consistency and completeness). Not surprisingly, in this case, most test suites from students were quite similar. Thus, in summary, the reuse potential of implementa- tion-driven and implementation-specific test cases is quite limited: each change to the IUT may require several test cases to be updated. In contrast, the explicit captur- ing of a suite of implementation-independ ent tests gener- ated from a requirements model offers two significant advantages: 1) It decouples requirements coverage [11] from the IUT: a suite of tests is generated from a requirements model according to some coverage criterion. Then, and only then, are tests somehow transformed into test cases proper (i.e., executable code artifacts specific to the IUT). Such test cases must be kept in sync with a constantly evolving IUT, but this can be done totally independently of requirements coverage. For example, how many spe- 2http://en.wikipedia.org/wiki/Yahtzee Copyright © 2013 SciRes. JSEA Traceability in Acceptance Testing 38 cific test cases are devoted to holding dice or to scoring a (valid or invalid) full house in Yahtzee, can be com- pletely decided before any code is written. 2) It enables reuse of a suite of tests across several IUTs, be they versions of a constantly evolving IUT or competing vendor-specific IUTs having to demonstrate compliance to some specification (e.g., in the domain of software radios). For example, as a third assignment per- taining to Yahtzee, students are asked to develop a graphical user interface (GUI) version of the game and demonstrate compliance of their implementation to the suite of tests (not test cases) we provide. Because per- formance and usability of the GUI are both evaluated, implementations can still vary (despite everyone essen- tially using the same “official” scoring sheet as the basis for the interface). However, a common suite of tests for compliance ensures all such submissions offer the same functionality, regard less of how differently this function - ality is realized in code. Beyond such methodological issues faced by code- based approaches to acceptance testing, because the latter requires automation (e.g., [11,12]), we must also con- sider tool suppor t for such appro a ches. Put simply, there is a multitude of tools for software testing (see [15,16]), even for specific domains such as Web quality assurance [17]. Bertolino [8] remarks, in her seminal review of the state-of-the-art in software testing, that most focus on functional testing, that is, check “that the observed behavior complies with the logic of the specifications”. From this perspective, it appears these tools are relevant to acceptance testing. A closer look reveals most of these tools are code-based testing tools (e.g., Java’s JUnit [18] and AutoTest [19]) that mainly focus on unit testing [11], that is, on testing individual procedures of an IUT (as opposed to scenario testing [20]). A few observations are in order: 1) There are many types of code-based verification tools. They include a plethora of static analyzers, as well as many other types of tools (see [21] for a short review). For example, some tackle design-by-contract [22], some metrics, some different forms of testing (e.g., regression testing [11]). According to the commonly accepted defi- nition of software testing as “the evaluation of software by observing its executions on actual valued inputs” [7], many such tools (in particular, static analyzers) are not testing tools per se as they do not involve the execution of code. 2) As stated previously, we postulate acceptance test- ing requires an implementation-independent require- ments model. While possibly feasible, it is unlikely this testable requirements model (hereafter TRM) would be at a level of details that would enable traceability between it and unit-level tests and/or test cases. That is, typically the tests proceeding from a TRM are system-level ones [11] (that is, intuitively, ones that view the system as a black box), not unit-level ones (i.e., specific to particular pro- cedures). Let us consider once more the issue of holding dice in the game of Yahtzee to illustrate this point. As mentioned earlier, there are several different ways of implementing this functio nality, leading to very different code. Tests pertaining to the holding of dice are derived from a TRM and, intuitively, involve determining: how many tests are sufficient for the desired coverage of this functionality what the first roll of each test would be (fixed values or random ones) and then for each test: what dice to hold after the first roll what the 2nd roll of each test would be (verifying whether holding was respected or not) whether a third roll occurs or not, and, if it does: a) what dice to hold after the second roll b) what the 3rd roll is (verifying whether holding was respected o r not) The resulting set of tests is implementation-indepen- dent and adopts a user perspective. It is a common mis- take however to have the creators of tests wrongfully postulate the existence of specific procedures in an im- plementation (e.g., a hold procedure with five Boolean parameters). This error allows the set of tests for holding to be expressed in terms of sequences of calls to specific procedures, thus incorrectly linking system-level tests with procedures (i.e., unit-level entities). In reality, au- tomatically inferring traceability between system-level tests and unit-level test cases is still, to the best of our knowledge, an open problem (whereas manual traceabil- ity is entirely feasible but impractical due to an obvious lack of scalability, as discussed shortly). Furthermore, we remark that the decision as to how many tests are suffi- cient for the desired coverage of the hold ing function ality must be totally independent of the implementation. (For example, it cannot be based on assuming that there is a hold procedure with 5 Boolean parameters and that we merely have to “cover” a sufficient number of combina- tions of these parameters. Such a tactic clearly omits se- veral facets of the set of tests suggested for the hold functionality.) Thus, in summary, tools conceived for unit testing cannot directly be used for acceptance testing. 3) Similarly, integration-testing tools (such as Fit/Fit- ness, EasyMock and jMock, etc.) do not address accep- tance testing proper. In particular, they do not capture a TRM per se. The same conclusion holds for test au toma- tion frameworks (e.g., IBM’s Rational Robot [23]) and test management tools (such as HP Quality Centre [24] and Microsoft Team Foundation Server [25]). One possible av enue to remedy th e absence of a TRM in existing code-based testin g tools may consist in trying Copyright © 2013 SciRes. JSEA Traceability in Accept an ce Testing 39 to connect such a tool with a requirements capture tool, that is, with a tool that captures a requirements model but does not generate tests or test cases from it. However, our ongoing collaboration with Blueprint [26] to attempt to link their software to code-based testing tools has re- vealed a fundamental hurdle with such a multi-tool ap- proach: Given there is no generation of test cases in Blueprint, traceability from Blueprint requirements3 to test cases (be they generated or merely captured in some code-based testing tool) currently reduces to manual cross-referencing. That is, there is currently no auto- mated way of connecting requirements with test cases. But a scalable approach to acceptance testing requires such automated traceability. Without it, the initial manual linking of (e.g., hundreds of) requirements to (e.g., pos- sibly thousands of) test cases (e.g., in the case of a me- dium-size system of a few tens of thousands lines of code) is simply unfeasible. (From this viewpoint, whether ei- ther or both tools at h and support chan ge impact analysis is irrelevant as it is the initial conn ecting of requirements to test cases that is most problematic.) At this point in time, the only observation we can add is that current ex- perimentation with Blueprint suggests an eventual solu- tion will require that a “semantic bridge” between this tool and a code-based testing tool be constructed. But this is possible only if both requirements and test cases are captured in such a way that they enable their own semantic analysis. That is, unless we can first have algo- rithms and tools that can “understand” requirements and test cases (by accessing and analyzing their underlying representations), we cannot hope to develop a semantic bridge between requirements and test cases. However, such “understanding” is extremely tool specific, which leads us to conclude that a multi-tool approach to accep- tance testing is unlikely in the short term (especially if one also has to “fight” a frequent unfavorable bias of users towards multi-tool solutions, due to their over- specificity, their cost, their learning curves, etc.). The need for an automated approach to traceability between requirements and test cases suggests the latter be somehow generated from the former. And thus we now turn to model-based approaches to acceptance test- ing. 3. Model-Based Testing In her review of software testing, Bertolino [8] remarks: “A great deal of research focuses nowadays on model- based testing. The leading idea is to use models defined in software construction to drive the testing process, in particular to automatically generate the test cases. The pragmatic approach that testing research takes is that of following what is the current trend in modeling: which- ever be the notation used, say e.g., UML or Z, we try to adapt to it a testing technique as effectively as possible [.]”. Model-Based Testing (MBT) [10,28,29] involves the derivation of tests and/or test cases from a model that describes at least some of the aspects of the IUT. More precisely, an MBT method uses various algorithms and strategies to generate tests (sometimes equivalently called “test purposes”) and/or test cases from a behav- ioral model of the IUT. Such a model is usually a partial representation of the IUT’s behavior, “partial” because the model abstracts away some of the implementation details. Several survey papers (e.g., [8,30,31) and special is- sues (e.g., [29]) have addressed such model-based ap- proaches, as well as the more specific model driven ones (e.g., [32,33]). Some have specifically targeted MBT tools (e.g., [28]). While some MBT methods use models other than UML state machines (e.g., [34]), most rely on test case generation from such state machines (see [35] for a survey). Here we will focus on state-based MBT tools that generate executable test cases. Thus we will not consider MBT contributions that instead only address the genera- tion of tests (and thus do not tackle the difficult issue of transforming such tests into executable IUT-specific test cases). Nor will we consider MBT methods that are not supported by a tool (since, tool support is absolutely re- quired in order to demonstrate the executability of the generated test cases). We start by discussing Conformiq’s Tool Suite [36,37], formerly known as Conformiq Qtronic (as referred to in [35]). This tool requires that a system’s requirements be captured in UML statecharts (using Conformiq’s Mod- eler or third party tools). It “generates software tests [...] without user intervention, complete with test plan docu- mentation and executab le test scripts in industry stand ard formats like Python, TCL, TTCN-3, C, C++, Visual Ba- sic, Java, JUnit, Perl, Excel, HTML, Word, Shell Scripts and others” [37]. This includes the automatic generation of test inputs (including structural data), expected test outputs, executable test suites, test case dependency in- formation and traceability matrix, as well as “support for boundary value analysis, atomic condition coverage, and other black-b o x test design heuristics” [Ibid.]. While such a description may give the impression ac- ceptance testing has been successfully completely auto- mated, extensive experimentation4 reveals some signifi- cant hurdles: First, Grieskamp [9], the creator of Spec Explorer [10], 3Blueprint offers user stories (which are a simple form of UML Use Cases [11,27]), UI Mockups and free-form text to capture requirements. The latter are by far the most popular but the hardest to semantically p rocess in an automated way. 4by the authors and 100+ senior undergraduate and graduate students in the context of offerings of a 4th year undergraduate course in Quality Assurance and a graduate course in Object Oriented Software Engi- neering twice over the last two years. Copyright © 2013 SciRes. JSEA Traceability in Acceptance Testing 40 another state-based MBT tool, explains at length the problems inherent to test case generation from state ma- chines. In particular, he makes it clear that the state ex- plosion problem remains a daunting challenge for all state-based MBT tools (contrary to the impression one may get from reading the few paragraphs devoted to it in the 360-page User Manual from Conformiq [37]). Indeed, even the modeling of a simple game like Yahtzee can require a huge state space if the 13 rounds of the game are to be modeled. Both tools (Conformiq and SpecEx- plorer) offer a simple mechanism to constrain the state “exploration” (or search) algorithm by setting bounds (e.g., on the maximum number of states to consider, or the “look ahead depth”). But then the onus is on the user to fix such boun ds through trial and erro r. And such con- straining is likely to hinder the completeness of the gen- erated tests. The use of “slicing” in Spec Explorer [10], via the specification of a scenario (see Figures 1-3), con- stitutes a much better solution to the problem of state explosion because it emphasizes the importance of equi- valence partitioning [11] and rightfully places on the user the onus of determining which scenarios are equiva- lent (a task that, as Binder explains [Ibid.], is unlikely to be fully automatable). (Figure 3 also conveys how tedi- ous (and non-scalable) the task of verifying the generated state machine can be even for a very simple scenario...) Second, in Conformiq, requirements coverage5 is only possible if states and transitions are manually associated // verify handling scoring “three of a kind” works // correctly: it must return the total of the d ice if 3 or // more are identical. // compute score for 36 end states with 3, 3, 3 as last dice // (ie only 2 first dice are random) // then compute score for the sole end state // corresponding to roll 2, 2, 1, 1, 3. // In that case, all dice are fixed and the game must // score 0 if that roll is scored as a three-of-a-kind machine ScoreThreeOfAKind() : RollConstraint { ( NewGame; (RollAll (_, _, 3, 3, 3); Score(ScoreType.ThreeOfAKind) | RollAll(2, 2, 1, 1, 3); Score(ScoreType.ThreeOfAKind))) || (construct model program from RollConstraint) // This last line is the one carrying out the slicing by // limiting a totally random roll of five dice to the // sequence of two rolls (and scoring) specified above it. } Figure 1. A Spec Explorer scenario for exploring scoring of three-of-a-kind rolls. // Sample hold test: we fix completely the first roll, // then hold its first 3 dice and roll again only 4th and 5 th // dice. // This test case gives 36 possible end states machine hold1() : RollConstraint { (NewGame; RollAll(1,1,1,1,1); hold(1); hold(2); hold(3); RollAll) || (construct model program from RollConstraint) } Figure 2. A Spec Explorer scenario for holding the first three dice. with requirements (which are thus merely annotations superimposed on a state machine)! Clearly, such a task lacks automation and scalability. Also, it points to an even more fundamental problem: requirements traceabil- ity, that is, the ability to link requirements to test cases. Shafique and Labiche [35, Table 4(b)] equate “require- ments traceability” with “integration with a requirements engineering tool”. Consequently, they consider that both Spec Explorer and Conformiq offer only “partial” sup- port for this problem. For example, in Conformiq, the abovementioned requirements annotations can be manu- ally connected to requirements captured in a tool such as IBM RequisitePro or IBM Rational DOORS [37, Chap ter 7]. However, we believe this operational view of re- quirements traceability downplays a more fundamental semantic problem identified by Grieskamp [9]: a sys- tem’s stakeholders are much more inclined to associate requirements to scenarios [20] (such as UML use cases [27]) than to elements of a state machine... From this viewpoint: 1) Spec Explorer implicitly supports the notion of sce- narios via the use of “sliced machines”, as previously illustrated. But slicing is a sophisticated technique draw- ing on semantically complex operators [10]. Thus, the state space generated by a sliced machine often may not correspond to the expectations of the user. This makes it all the more difficult to conceptually and then manually link the requirements of stakeholder’s to such scenarios. For example, in the case of Yahtzee, a sliced machine can be obtained quite easily for each of the 13 scoring categories of the game (see Figures 1 and 3). Traceabil- ity from these machines to the requirements of the game is quite straightforward (albeit not automated). Con- versely, other aspects of the game (such as holding dice, ensuring no more than 3 rolls are allowed in a single round, ensuring that no category is used more than once pe r g am e, en sur in g t ha t e xactly 13 rounds are played, etc.) require several machines in order to obtain sufficient coverage. In particular, the machine of Figure 2 is not sufficient to test holding dice. Clearly, in such cases, traceability is not an isomorphism between sliced ma- chines and requirements. Finally, there are aspects of 5Not to be confused with state machine coverage, nor with test suite coverage, both of these being directly and quite adequately addressed by Conformiq and Spec Explorer [35 , Tables 2 and 3]. Copyright © 2013 SciRes. JSEA Traceability in Accept an ce Testing Copyright © 2013 SciRes. JSEA 41 Figure 3. A part of the generated sliced state machine for scoring of three-of-a-kind rolls. Yahtzee that are hard to address with state machines and/or scenarios. For example, a Yahtzee occurs when all five dice have the same value at the end of a round. Yahtzee is the most difficult combination to throw in a game and has the highest score of 50 points. Without going into details, if a player obtains more than one Yaht- zee during a same game, these additional Yahtzees can be used as wild cards (i.e., score full points in other ca- tegories). For example, a second Yahtzee could be used as a long straight! Such behavior (wild cards at any point in time) drastically complicates models (leading most who attempt to address this feature to later abandon it...). In fact, the resulting models are so much more complex that: getting slicing to work correctly is very challenging (read time-consuming, in terms of modeling and veri- fication of the generated machines), especially given insufficient slicing will lead to state exploration fail- ing upon reaching some upper bound (making it even more difficult to decide if the partially generated ma- chine is correct or not). Such a situation typically leads to oversimplifications in the model and/or the slicing scenarios... traceability between such machines and the game requirements is not obvious. That is, even someone who is an expert with the game and with Spec Ex- plorer will not necessarily readily know what a par- ticular sliced machine is exactly testing. (This is par- ticularly true when using some of the more powerful slicing operators whose behavior must be thoroughly understood in order to decide if the behavior they generate corresponds or not to what the tester in- tends.) 2) Conformiq does support use cases, which can be linked to requirements and can play a role in test case generation [37, p. 58]. Thus, instead of having the user manually connect requirements to elements of a state machine, a scenario-based approach to requirements traceability could be envisioned. Intuitively this approach would associated a) requirements with use cases and b) paths of use cases with series of test cases. But, unfortu- nately, this would require a totally d ifferent algorithm for test case generation than the one Conformiq uses. Such an algorithm would not be rooted in state machines but in path sensitization using scenarios [11] and this would lead to a totally different tool. Third, test case executability may not be as readily available as what the user of an MBT tool expects. Con- sider for example, the notion of a “scripting backend” in Conformiq Designer. For example [37, p. 131]: “The TTCN-3 scripting backend publishes tests generated by Conformiq Designer automatically in TTCN-3 and saves them in TTCN-3 files. TTCN-3 test cases are executed against a real system under test with a TTCN-3 runtime environment and necessary adapters.” The point to be grasped is (what is often referred to as) “glue code” is required to connect the generated tests to an actual IUT. Though less obvious from the documentation, the same observation holds for the other formats (e.g., C++, Perl, etc.) for which Conformiq offers such backends. For example, we first read [37, p. 136]: “With Perl script backend, Perl test cases can be derived automatically from a functional design model and be executed against a real system.” And then find out on the next page that this in fact requires “the location of the Perl test harness module, i.e., the Perl module which contains the imple- mentation of the routines that the scripting backend gen- erates.” In other words, Conformiq does provide not only test cases but also offers a (possibly 3rd party) test har- ness [Ibid.] that enables their execution against an IUT. But its user is left to create glue code to bridge between these test cases and the IUT. This manual task is not only time-consuming but potentially error-prone [11]. Also, this glue code is implementation-specific and thus, both its reusability across IUTs and its maintainability are problematic. Traceability in Acceptance Testing 42 In Spec Explorer [10], each test case corresponds to a specific path through a generated ‘sliced’ state machine. One alternative is to have each test case connected to the IUT by having the rules of the specification (which are used to control state exploration, as illustrated shortly) explicitly refer to procedures of the IUT. Alternatively, an adapter (i.e., glue code) can be written to link these test cases with the IUT. That is, once again, traceability to the IUT is a manual task. Furthermore, in this tool, test case execution (which is completely integrated into Vis- ual Studio) relies on the IUT inputting test case specific data (captured as parameter values of a transition of the generated state machine) and outputting the expected results (captured in the model as return values of these transitions). As often emphasized in the associated tuto- rial videos (especially, Session 3 Part 2), the state vari- ables used in the Spec Explorer rules are only relevant to state machine exploration, not to test case execution. Thus any probing into the state of the IUT must be ex- plicitly addressed throug h the use of such parameters and return values. The challenge of such an approach can be illustrated by returning to our Yahtzee example. Consider the rule (Figure 4) called RollAll (used in Figures 1 and 2) to capture the state change corresponding to a roll of the dice. In the rule RollAll, numRolls, numRounds, numHeld, diHeld and diVal are all state variables. Withou t going in details, this rule enables all valid rolls (with respect to the number of rounds, the number of rolls and which dice are to be held) to be potential next states. So, if before firing this rules the values for diVal were {1, 2, 3, 4, 5} and those of the diHeld were {true, true, true, true, false}, then only rolls that have the first 4 dice (which are held) as {1, 2, 3, 4} are valid as next rolls. The problem is that {1, 2, 3, 4, 5} is valid as a next roll. But, when testing against an IUT, this rule makes it impossible to verify whether the last dice was held by mistake or actually rerolled and still gave 5. The solution attempted by stu- dents given this exercise generally consists in adding 5 more Boolean parameters to RollAll: each Boolean indi- cating if a die is held or not. The problem with such a solution is that it leads to state explo sion. More specifically: 1) the rule RollAll(int d1, int d2, int d3, int d4, int d5) has 65 = 7776 po ssible nex t states but 2) the rule RollAll(int d1, int d2, int d3, int d4, int d5, boolean d1Held, boolean d2Held, boolean d3Held, boo- lean d4Held, boolean d5Held) has 65 * 25 = 248,832 possibl e n e xt states . A round for a player may consist of up to 3 rolls, each one using RollAll to compute its possible next states. In the first version of this rule, if no constraints are used, each of the 7776 possible next states of the first roll has itself 7776 possible next states. That amounts to more [Rule] static void RollAll(int d1 , int d2, int d3, int d4, int d5) { // We can roll if we haven’t rolled 3 times already for this // round and if we still have a round to play and score Condition.IsTrue(numRolls < 3); Condition.IsTrue(numRounds < 13); // if this is the first roll for this round, // then make sure no die is held if (numRolls == 0) { Condition.IsTrue(numHeld == 0); } else { // the state variables diVal hold the values of the dice // from the previous roll // if a dice is held then th e ne w value di of dice i, // which is a parameter to this rule must be the same as // the previous value of this die. Condition.IsTrue(!d1Held || d1 == d1Val); Condition.IsTrue(!d2Held || d2 == d2Val); Condition.IsTrue(!d3Held || d3 == d3Val); Condition.IsTrue(!d4Held || d4 == d4Val); Condition.IsTrue(!d5Held || d5 == d5Val); /* store values from this roll in the state variables*/ d1Val = d1; d2Val = d2; d3Val = d3; d4Val = d4; d5Val = d5; } // of else clause // increment the state variable that keeps track // of the number of rolls for this round. numRolls += 1; } Figure 4. Rule RollAll. than 60 million states and we have yet to deal with a pos- sible third roll. The explosion of states is obviously even worse with the second version of the RollAll rule: after two rolls there are 61 billion possible states... State ex- ploration will quickly reach the specified maximum for the number of generated states, despite the sophisticated state-clustering algorithm of SpecExplorer. Furthermore, unfortunately, an alternative design for modeling the holding of dice is anything but intuitive as it requires using the return value of this rule to indicate, for each die, if it was held or not... The key point to be grasped from this example is that, beyond issues of scalability and traceability, one funda- mental reality of all MBT tools is that their semantic in- tricacies can significantly impact on what acceptance testing can and cannot address. For example, in Yahtzee, given a game consists of 13 rounds to be each scored once into one of the 13 categories of the scoring sheet, a tester would ideally want to see this scoring sheet after each roll in order to ensure not only that the most recent roll has been scored correctly but also that previous Copyright © 2013 SciRes. JSEA Traceability in Accept an ce Testing 43 scores are still correctly recorded. But achieving this is notoriously challenging in SpecExplorer (unless it is ex- plicitly programmed into the glue code that connects the test cases to the IUT; an approach that is less than ideal in the context of automated testing). We discuss further the issue of semantics in the con- text of traceability for acceptance testing in the next sec- tion. 4. On Semantics for Acceptance Testing There ex ists a large body of work on “specification s” for testing, as discussed at length in [38]. Not surprisingly, most frequently such work is rooted in state-based se- mantics6. For example, recently, Zhao and Rammig [40] discuss the use of a Büschi automaton for a state-oriented form online model checking. In the same vein, COMA [41], JavaMOP [42] and TOPL [43] offer implemented approaches to runtime verification. The latter differs from acceptance testing inasmuch as it is not concerned with the generation of tests but rather with the analysis of an execution in order to detect the violation of certain properties. Runtime verification specifications are typi- cally expressed in trace predicate formalisms, such as finite state machines, regular expressions, context-free patterns, linear temporal logics, etc. (JavaMOP stands out for its ability to support se veral of these formalisms.) While “scenarios” are sometimes mentioned in such me- thods (e.g., [44]), they are often quite restricted semanti- cally. For example, Li et al. [45] use UML sequence dia- grams with no alternatives or loops. Ciraci et al. [46] explains that the intent is to have such “simplified” sce- narios generate a graph of all possible sequences of exe- cutions. The difficulty with such strategy is th at it gener- ally does not scale up, as demonstrated at length by Bri- and and Labiche [47]7. Similarly, i n MB T , Cu cumber i s a tool rooted in BDD [48], a user-friendly language for expressing scenarios. But these scenarios are extremely simple (nay simplistic) compared to the ones expressible using slicing in SpecExplorer [10]. It must be emphasized that not all approaches to run-time verification that use scenario-based specifica- tions depend on simplified semantics. In particular, Krü- ger, Meisinger and Menarini [49] rely on the rich seman- tics of Message Sequence Charts [50], which they extend! But, like many similar approaches, they limit themselves to monitoring sequences of procedures (without parame- ters). Also, they apply their state machine synthesis algo- rithm to obtain state machines representing the full communication behavior of individual components of the system. Such synthesized state machines are at the centre of their monitoring approach but are not easy to trace back to the requirements of a system’s stakeholders. Furthermore, all the approaches to runtime verification we have studied rely on specifications that are imple- mentation (and often programming language) specific. For example, valid sequences are to be expressed using the actual names of the procedures of an implementation, or transitions of a state machine are to be triggered by events that belong to a set of method names. Thus, in summary, it appears most of this research bypasses the problem of traceability between an implementation-in- dependent specification and implementation-specific ex- ecutable tests, which is central to the task of acceptance testing. Requirements coverage may also be an issue de- pending on how many (or how few) execution traces are considered. Furthermore, as is the case for most MBT methods and tools, complex temporal scenario inter-re- lationships [20] are often ignored in runtime verification approaches (i.e., temporal considerations are limited to the sequencing of procedures with little atten tio n giv en to temporal scenario inter-relations hips). At this point of the discussion, we observe that trace- ability between implementation-independent specifica- tions and execu table IUT-specific test cases remains pro- blematic in existing work on MBT and, more generally, in specifications for testing. Hierons [38], amongst others, comes to the same conclusion. Therefore, it may be use- ful to consider modeling approaches not specifically tar- geted towards acceptance testing but that appear to ad- dress traceability. First, consider the work of Cristia et al. [51] on a lan- guage for test refinements rooted in (a subset of) the Z notation (which has been investigated considerably for MBT [Ibid.]). A refinement requires: “Identifying the SUT’s [System Under Test] state variables and input parameters that correspond to the specification variables Initializing the implementation variables as specified in each abstract test case Initializing implementation v a riables used by the SUT but not considered in the specification Performing a sound refinement of the values of the abstract test cases into values for the implementation variables.” A quick look at the refinement rule found in Figure 3 of [51] demonstrates eloquently how implementation- specific such a rule is. Thus, our traceability problem remains. In the same vein, Microsoft’s FORMULA (Formal Modeling Using Logic Programming and Analysis) [52] is: 6Non state-based approaches do exist but are quite remote from accep- tance testing. For example, Stoller et al. [39] rely on Hidden Markov Models to propose a particular type of runtime verification rooted in computing the probability of satisfying an aspect of a specification. 7Imposing severe semantic restrictions on scenarios serves the purpose of trying to limit this graph of all possible sequences of execution. But if loops, alternatives and interleaving are tackled, then the number o f p ossible sequences explodes. Copyright © 2013 SciRes. JSEA Traceability in Acceptance Testing 44 “A modern formal specification language targeting model-based development (MBD). It is based on alge- braic data types (ADTs) and strongly-typed constraint logic programming (CLP), which support concise speci- fications of abstractions and model transformations. Around this core is a set of composition operators for composing specifications in the style of MBD.” [Ibid.] The problem is that the traceability of such specifica- tions to a) a requirements model understandable by stakeholders and b) to an IUT remains a hurdle. In contrast, the philosophy of model-driven design (MDD) [53] that “the model is the code” seems to elimi- nate the traceability issue between models and code: code can be easily regenerated every time the model changes8. And since, in MDD tools (e.g., [54]), code gen- eration is based on state machines, there appears to be an opportunity to reuse these state machines not just for code generation but also for test case generation. This is indeed feasible with Conformiq Designer [36], which allows the reuse of state machines from third party tools. But there is a major stumbling block: while both code and test cases can be generated (albeit by different tools) from the same state machines, they are totally independ- ent. In other words, the existence of a full code generator does not readily help with the problem of traceability from requirements to test cases. In fact, because the code is generated, it is extremely difficult to reuse it for the construction of the scriptends that would allow Confor- miq’s user to connect test cases to this generated IUT. Moreover, such a strategy defeats the purpose of full code generation in MDD, which is to have the users of an MDD tool never have to deal with code directly (except for defining the actions of transitions in state machines). One possible avenue of solution would be to develop a new integrated generator that would use state machines to generate code and test cases for this code. But trace- ability of such test cases back to a requirements models (especially a scenario-driven one, as advocated by Gri- eskamp [9]), still remains unaddressed. Thus, at this point in time, the traceability offered in MDD tools by virtue of full code generation does not appear to help with the issue of traceability between requirements and test cases for acceptance testing. Furthermore, one must also acknowledge Selic’s [53] concerns about the rela- tively low level of adoption of MDD tools in industry. In the end, despite the dominant trend in MBT of adopting state-based test and test case generation, it may be necessary to consider some sort of scenario-driven generation of test cases from requirements for acceptance testing. This seems eventually feasible given the follow- ing concluding observations: 1) There is already work on generating tests out of use cases [55] and use case maps [56,57], and generating test cases out of sequence diagrams [58,59]. Path sensitiza- tion [11,12] is the key technique typically used in these proposals. There are still open problems with path sensi- tization [Ibid.]. In particular, automating the identifica- tion of the variables to be used for path selection is chal- lenging. As is the issue of path coverage [Ibid.] (in light of a potential explosion of the number of possible paths in a scenario model). In other words, the fundamental problem of equivalence partitioning [11] remains an im- pediment and an automated solution for it appears to be quite unlikely. However, despite these observations, we remark simple implementations of this technique already exist (e.g., [56] for Use Case Maps). 2) Partial, if not ideally fully automated, traceability between use cases, use case maps and sequence diagrams can certainly be envisioned given their semantic close- ness, each one in fact refining the pre vious one. 3) Traceability between sequence diagrams (such as Message Sequence Charts [50]) and an IUT appears quite straightforward given the low-level of abstraction of such models. 4) Within the semantic context of path sensitization, tests can be thought of as paths (i.e., sequences) of ob- servable responsibilities (i.e., small testable functional requirements [57]). Thus, because tests from use cases, use case maps and sequence diagrams are all essentially paths of responsibilities, and because responsibilities ulti- mately map onto procedures of the IUT, automated trace- ability (e.g., via type inference as proposed in [60]) be- tween tests and test cases and between test cases and IUT seems realizable. 5. Acknowledgements Support from the Natural Sciences and Engineering Re- search Council of Canada is gratefully acknowledged. REFERENCES [1] P. Kruchten, “The Rational Unified Process,” Addison- Wesley, Reading, 2003. [2] D. Rosemberg and M. Stephens, “Use Case Driven Ob- ject Modeling with UML,” Apress, New York, 2007. [3] K. Beck, “Test-Driven Development: By Example,” Ad- dison-Wesley Professional, Reading, 2002. [4] C. Jones and O. Bonsignour, “The Economics of Soft- ware Quality,” Addison-Wesley Professional, Reading, 2011. 8As one of the original creators of the ObjecTime toolset, which has evolved in Rational Rose Technical Developer [54], the first author o f this paper is well aware of the semantic and scalability issues facing existing MDD tools. But solutions to these issues are not as relevant to acceptance testing as the problem of traceability. [5] R. Johnson, “Avoiding the Classic Catastrophic Com- puter Science Failure Mode,” Proceedings of the 18th ACM SIGSOFT International Symposium on Foundations of Software Engineering, Santa Fe, 7-11 November 2010, Copyright © 2013 SciRes. JSEA Traceability in Accept an ce Testing 45 [6] M. Surhone, M. Tennoe and S. Henssonow, “Cisq,” Be- tascript Publishing, New York, 2010. [7] P. Ammann and J. Offutt, “Introduction to Software Test- ing,” Cambridge University Press, Cambridge, 2008. http://dx.doi.org/10.1017/CBO9780511809163 [8] A. Bertolino, “Software Testing Research: Achievements, Challenges and Dreams,” Proceedings of Future of Soft- ware Engineering (FOSE 07), Minneapolis, 23-25 May 2007, pp. 85-103. [9] W. Grieskamp, “Multi-Paradigmatic Model-Based Test- ing,” Technical Report, Microsoft Research, Seattle, 2006, pp. 1-20. [10] Microsoft, “Spec Explorer Visual Studio Power Tool,” 2013. http://visualstudiogallery.msdn.microsoft.com/271d0904- f178-4ce9-956b-d9bfa4902745 [11] R. Binder, “Testing Object-Oriented Systems,” Addison- Wesley Professional, Reading, 2000. [12] J.-P. Corriveau, “Testable Requirements for Offshore Out- sourcing,” Proceedings of Software Engineering Ap- proaches for Offshore and Outsourced Development (SEAFOOD), Springer, Berlin, 2007, pp. 27-43. http://dx.doi.org/10.1007/978-3-540-75542-5_3 [13] B. Meyer, “The Unspoken Revolution in Software Engi- neering,” IEEE Computer, Vol. 39, No. 1, 2006, pp. 121- 123. [14] J.-P. Corriveau, “Traceability Process for Large OO Pro- jects,” IEEE Computer, Vol. 29, No. 9, 1996, pp. 63-68. http://dx.doi.org/10.1109/2.536785 [15] “List of Testing Tools,” 2013. http://www.softwaretestingclass.com/software-testing-too ls-list [16] Wikipedia, “Second List of Testing Tools,” 2013. http://en.wikipedia.org/wiki/Category:Software_testing_t ools [17] “Testing Tools for Web QA,” 2013. http://www.aptest.com/webresources.html [18] “JUnit,” 2013. http://www.junit.org [19] B. Meyer, et al., “Programs that Test Themselves,” IEEE Computer, Vol. 42, No. 9, 2009, pp. 46-55. http://dx.doi.org/10.1109/MC.2009.296 [20] J. Ryser and M. Glinz, “SCENT: A Method Employing Scenarios to Systematically Derive Test Cases for System Test,” Technical Report, University of Zurich, Zurich, 2003. [21] D. Arnold, J.-P. Corriveau and W. Shi, “Validation aga- inst Actual Behavior: Still a Challenge for Testing Tools,” Proceedings of Software Engineering Research and Prac- tice (SERP), Las Vegas, 12-15 July 2010. [22] B. Meyer, “Design by Contract,” IEEE Computer, Vol. 25, No. 10, 1992, pp. 40-51. http://dx.doi.org/10.1109/2.161279 [23] “IBM Rational Robot,” 2013. http://www-01.ibm.com/software/awdtools/tester/robot [24] “HP Quality Centre,” 2013. http://www8.hp.com/ca/en/software-solutions/software.ht ml?compURI=1172141#.UkDyk79AiHk [25] “Team Foudation Server,” 2013. http://msdn.microsoft.com/en-us/vstudio/ff637362.aspx [26] “Blueprint,” 2013. https: //docume ntation. blue printcl oud.co m/Blue print 5.1/De fa ult.htm#Help/Project%20Administration/Tasks/Managing %20ALM%20targets/Creating%20ALM%20targets.htm [27] Object Management Group (OMG), “UML Superstruc- ture Specification v2.3,” 2013. http://www.omg.org/spec/UML/2.3 [28] M. Utting and B. Legeard, “Practical Model-Based Test- ing: A Tools Approach,” Morgan Kauffmann, New York, 2007. [29] “Special Issue on Model-Based Testing,” Testing Ex- perience, Vol. 17, 2012. [30] M. Prasanna, et al., “A Survey on Automatic Test Case Generation,” Academic Open Internet Journal, Vol. 15, No. 6, 2005. [31] A. Neto, R. Subramanyan, M. Vieira and G. H. Travassos, “A Survey of Model-Based Testing Approaches,” Pro- ceedings of the 1st ACM International Workshop on Em- pirical Assessment of Software Engineering Languages and Technologies (WEASELTech 07), Atlanta, 5 Novem- ber 2007, pp. 31-36. [32] P. Baker, Z. R. Dai, J. Grabowski, I. Schieferdecker and C. Williams, “Model-Driven Testing: Using the UML Pro- file,” Springer, New York, 2007. [33] S. Bukhari and T. Waheed, “Model Driven Transforma- tion between Design Models to System Test Models Us- ing UML: A Survey,” Proceedings of the 2010 National S/w Engineering Conference, Rawalpindi, 4-5 October 2010, Article 08. [34] “Seppmed,” 2013. http://wiki.eclipse.org/EclipseTestingDay2010_Talk_Sep pmed [35] M. Shafique and Y. Labiche, “A Systematic Review of Model Based Testing Tool Support,” Technical Report SCE-10-04, Carleton University, Ottawa, 2010. [36] “Conformiq Tool Suite,” 2013. http://www.verifysoft.com/en_conformiq_automatic_test _generation.html [37] “Conformiq Manual,” 2013. http://www.verifysoft.com/ConformiqManual.pdf [38] R. Hierons, et al., “Using Formal Specifications to Sup- port Testing,” ACM Computing Surveys, Vol. 41, No. 2, 2009, pp. 1-76. http://dx.doi.org/10.1145/1459352.1459354 [39] S. D. Stoller, et al., “Runtime Verification with State Esti- mation,” Proceedings of 11th International Workshop on Runtime Verification (RV'11), Springer, Berlin, 2011, pp. 193-207. [40] Y. Zhao and F. Rammig, “Online Model Checking for Dependable Real-Time Systems,” Proceedings of the IEEE 15th International Symposium on Object/Component/Ser- vice-Oriented Real-Time Distributed Computing, Shenzhen, 11-13 April 2012, pp. 154-161. Copyright © 2013 SciRes. JSEA Traceability in Acceptance Testing Copyright © 2013 SciRes. JSEA 46 [41] P. Arcaini, A. Gargantini and E. Riccobene, “CoMA: Conformance Monitoring of Java Programs by Abstract State Machines,” Proceedings of 11th International Work- shop on Runtime Verification (RV'11), Springer, Berlin, 2011, pp. 223-238. [42] D. Jin, P. Meredith, C. Lee and G. Rosu, “JavaMOP: Efficient Parametric Runtime Monitoring Framework,” Proceedings of the 34th International Conference on Soft- ware Engineering (ICSE), Zurich, 2-9 June 2012, pp. 1427- 1430. [43] R. Grigor, et al., “Runtime Verification Based on Regis- ter Automata,” Proceedings of the 19th International Conference on Tools and Algorithms for the Construction and Analysis of Systems (TACAS), Springer, Berlin, 2013, pp. 260-276. [44] Z. Zhou, et al., “Jasmine: A Tool for Model-Driven Run- time Verification with UML Behavioral Models,” Pro- ceedings of the 11th IEEE High Assurance Systems Engi- neering Symposium (HASE), Nanjing, 3-5 December 2008, pp. 487-490. [45] X. Li, et al., “UML Interaction Model-Driven Runtime Verification of Java Programs,” Software, IET, Vol. 5, No. 2, 2011, pp. 142-156. [46] S. Ciraci, S. Malakuti, S. Katz, and M. Aksit, “Checking the Correspondence between UML Models and Imple- mentation,” Proceedings of 10th International Workshop on Runtime Verification (RV'10), Springer, Berlin, 2011, pp. 198-213. [47] L. Briand and Y. Labiche, “A UML-Based Approach to System Testing,” Software and Systems Modeling, Vol. 1, No. 1, 2002, pp. 10-42. http://dx.doi.org/10.1007/s10270-002-0004-8 [48] D. Chelimsky, et al. “The RSpec Book: Behaviour Driven Development with Rspec, Cucumber and Friends,” Prag- matic Bookshelf, New York, 2010. [49] I. H. Krüger, M. Meisinger and M. Menarini: “Runtime Verification of Interactions: From MSCs to Aspects,” Proceedings of 7th International Workshop on Runtime Verification (RV'07), Springer, Berlin, 2007, pp. 63-74. [50] International Telecommunication Union (ITU), “Message Sequence Charts, ITU Z.120,” 2013. http://www.itu.int/rec/T-REC-Z.120 [51] M. Cristiá, P. Rodríguez Monetti, and P. Albertengo, “The Fastest 1.3.6 User’s Guide,” 2013. http://www.flowgate.net/pdf/userGuide.pdf [52] Microsoft, “FORMULA,” 2013. http://research.microsoft.com/en-us/projects/formula/ [53] B. Selic, “Filling in the Whitespace,” http://lmo08.iro.umontreal.ca/Bran%20Selic.pdf [54] “Rational Technical Developer,” http://www-01.ibm.com/software/awdtools/developer/tec hnical [55] C. Nebut, et al., “Automatic Test Generation: A Use Case Driven Approach,” IEEE Transactions on Software Engi- neering, Vol. 32, No. 3, 2006, pp. 140-155. http://dx.doi.org/10.1109/TSE.2006.22 [56] A. Miga, “Applications of Use Case Maps to System Design with Tool Support,” Master’s Thesis, Carleton University, Ottawa, 1998. [57] D. Amyot and G. Mussbac her, “User Requirements Nota- tion: The First Ten Years”, Journal of Software, Vol. 6, No. 5, 2011, pp. 747-768. [58] J. Zander, et al., “From U2TP Models to Executable Tests with TTCN-3—An Approach to Model Driven Testing,” Proceedings of the 17th International Conference on Test- ing Communicating Systems, Montreal, 31 May-2 June 2005, pp. 289-303. http://dx.doi.org/10.1007/11430230_20 [59] P. Baker and C. Jervis, “Testing UML 2.0 Models using TTCN-3 and the UML 2.0 Testing Profile,” Springer, Berlin, 2007, pp. 86-100. [60] D. Arnold, J.-P. Corriveau and W. Shi, “Modeling and Validating Requirements Using Executable Contracts and Scenarios,” Proceedings of Software Engineering Resear- ch, Management & Applications (SERA 2010), Montreal, 24-26 May 2010, pp. 311-320. |
