ABSTRACT

An exact analysis of the flow of an incompressible viscous fluid past an infinite vertical plate is conducted taking into account the presence of foreign mass or constant mass flux and ramped wall temperature. The dimensionless governing coupled linear partial differential equations are solved using the Laplace transform technique. Two different solutions for the fluid velocity are obtained–one valid for the fluids of Schmidt numbers different from unity, and the other for which the Schmidt number is unity. The effects of Prandtl number (Pr), Schmidt number (Sc), time (t) and mass to thermal buoyancy ratio parameter (N) for both aiding and opposing buoyancy effects on the velocity and skin-friction are studied. Also, the heat and mass transfer effects on the flow near a ramped temperature plate have been compared with the flow near a plate with constant temperature.

1. Introduction

Free convection flows past a vertical surface or plate have been studied extensively in the literature due to applications in engineering and environmental processes. Several investigations were performed using both analytical and numerical methods under different thermal conditions which are continuous and well-defined at the wall. Practical problems often involve wall conditions that are non-uniform or arbitrary. To understand such problems, it is useful to investigate problems subject to step change in wall temperature. For example in the fabrication of thin-film photovoltaic devices ramped wall temperatures may be employed to achieve a specific finish of the system [1]. Periodic temperature step changes are also important in building heat transfer applications, for example in air conditioning, where the conventional l assumption of periodic outdoor conditions may lead to considerable errors in the case of a significant temporary deviation of the temperature from periodicity, as elaborated by Antonopoulos and Democritou [2]. Other examples include nuclear heat transfer control, materials processing, turbine blade heat transfer, electronic circuits and sealed gas-filled enclosure heat transfer operations [3]. Schetz [4] presented one of the earliest analytical studies for free convection flow from a vertical plate with discontinuous wall temperature conditions. Several investigations were continued on this problem using an experimental technique [5], numerical methods [6], and by using series expansions [7,8]. Lee and Yovanovich [9] presented a new analytical model for the laminar natural convection from a vertical plate with step change in wall temperature. The validity and accuracy of the model is demonstrated by comparing with the existing results. Chandran et al. [10] have presented an analytical solution to the unsteady natural convection flow of an incompressible viscous fluid near a vertical plate with ramped wall temperature and they have compared the results with constant temperature. Recently, Saha et al. [11] investigated the natural convection boundary layer adjacent to an inclined semi-infinite flat plate subjected to ramp heating. The flow development from the start-up to an eventual steady state has been described based on scaling analysis and verified by numerical simulations. Chaudhary and Jain [12] developed closed-form solutions to the unsteady free convection flow past an infinite vertical oscillating plate for the scenario where the bounding plate has a ramped temperature profile using the Laplacetransform technique.

Free convection flows occur not only due temperature difference, but also due to concentration difference or the combination of these two. The study of combined heat and mass transfer play an important role in the design of chemical processing equipment, nuclear reactors, formation and dispersion of fog etc. Both steady-state and transient double-diffusive convection flows are of importance. The effect of presence of foreign mass on the free convection flow past a semi-infinite vertical plate was first studied by Gebhart and Pera [13]. Chen et al. [14] studied the combined double-diffusive mixed convective boundary layer flow from vertical and inclined surfaces. Bég et al. [15] extended the study in [14] to consider the supplementary effects of chemical reaction and cross-diffusion (Soret and Dufour effects) on mixed convection heat and mass transfer flows from inclined plates, using a numerical method. Soundalgekar [16] has studied mass transfer effects on thermal convection flow past an impulsively started infinite isothermal vertical plate. Dass et al. [17] considered the mass transfer effects on flow past an impulsively started infinite isothermal vertical plate with constant mass flux. Muthucumaraswamy et al. [18] presented an exact solution to the problem of flow past an impulsively started infinite vertical plate in the presence of uniform heat and mass flux at the plate using Laplace transforms.

However, mass transfer effects on free convection flow past an infinite vertical plate subject to discontinuous or non-uniform wall temperature conditions have not been studied in the literature. Hence it is now proposed to study the effects of mass transfer on the free convection flow of an incompressible viscous fluid past an infinite vertical plate subject to ramped wall temperature for the cases of 1) foreign mass and 2) constant mass flux at the plate. In section 2 the mathematical analysis is presented. In section 3 exact solutions to the non-dimensional coupled linear partial differential equations are derived by the Laplace transform method.

2. Mathematical Model

Consider the flow of a viscous incompressible fluid past an infinite vertical plate. The - axis is taken along the plate in the vertically upward direction, and the - axis is taken normal to the plate. Initially, for time, both the plate and the fluid are assumed to be at the same temperature, concentration, and stationary. At time, the temperature of the plate is raised or lowered to when, and thereafter, i.e. for, is maintained at the constant temperature and the concentration level at the plate is raised to or concentration is supplied at a constant rate to the plate. Then under usual Boussinesq’s approximation, the unsteady flow past an infinite vertical plate is governed by the following equations [16-18]:

(1)

(2)

(3)

subject to the following initial and boundary conditions:

(4)

As the plate is assumed to be infinite in length, the physical variables are functions of and only. Here is the velocity in the direction, the time, the acceleration due to gravity, the volumetric coefficient of thermal expansion, the volumetric coefficient of expansion for concentration, the temperature of the fluid near the plate, the temperature of the fluid far away from the plate, the species concentration near the plate, the species concentration in the fluid far away from the plate, the plate temperature, the species concentration at the plate, the characteristic time, the kinematic viscosity, the density, the specific heat at constant pressure, the thermal conductivity of the fluid, the mass flux per unit area at the plate and D is the mass diffusion coefficient. To facilitate analytical solutions we introduce the following non-dimensional quantities (see Equation (5)):

(5)

Implementation of the non-dimensional variables (5) in Equations (1) - (4), leads to the following group of linear, second order, first degree, coupled partial differential equations for momentum, heat and species diffusion conservation:

(6)

(7)

(8)

where u the dimensionless velocity, y the dimensionless coordinate axis normal to the plate, t the dimensionless time, θ the dimensionless temperature, C the dimensionless concentration, Gr thermal Grashof number, Gm mass Grashof number, Pr the Prandtl number, μ the coefficient of viscosity, Sc the Schmidt number, and N is the buoyancy ratio parameter. According to the above nondimensionalisation process, the characteristic time can be defined as:

(9)

The corresponding initial and boundary conditions in dimensionless form are shown in Equation (10):

(10)

3. Analytical Laplace Transform Solutions

These equations (6) - (8) are a strongly coupled linear system of equations, which can be solved by the Laplace transform technique subject to the initial and boundary conditions (10). The solutions are readily yielded as:

Case I:

   (Foreign mass)(11a)

(Constant mass flux) (11b)

(12)

(Foreign mass)(13a)

(Constant mass flux)(13b)

Case II:

(Foreign mass) (14a)

(Constant mass flux)(14b)

where

(14c)

where is the unit step function defined, in general, by:

(15)

Here a is a constant, z is a dummy variable and are functions of dummy variable. Moreover, concentration [10,12] and temperature [7] profiles given by Equations (11) and (12) respectively, are well known. Equations (11), (12) and (13) give analytical expressions for the concentration, temperature and velocity variables for flow near a vertical plate with ramped temperature. In order to highlight the effect of the ramped temperature distribution of the boundary on the flow, it may be worthwhile to compare such a flow with the one near a plate with constant temperature. Under the assumptions employed in this paper, it can be shown that the temperature and velocity variables for the flow near a plate with constant temperature can be expressed as

(16)

(Foreign mass)(17a)



(Constant mass flux)(17b)

Equation (16) is valid only in the case of 1; for the case the velocity can be expressed as

(Foreign mass)(18a)

(Constant mass flux)(18b)

and there is no change in the expression for concentration variable. From the velocity field, it is now proposed to study the effects of mass transfer on the skin-friction, the latter being defined in non-dimensional form as:

(19)

We obtain for the case of a ramped temperature plate:

(Foreign mass) (20)

(Constant mass flux)(21)

and for the constant temperature (isothermal) plate,

(Foreign mass)(22)

(Foreign mass)(23)

It is seen that the expressions for is valid for all values of Pr and Sc in both the cases. Also, we can see that varies inversely with and in both cases.

4. Results and Discussion

In order to get physical insight into the problem, the numerical values of the velocity and skin-friction are computed as functions of time for different values of the system parameters such as Pr, Sc and N. In the present analytical solutions, we have only considered 2 values of Pr i.e. 0.71 and 7.0. The two most frequently encountered fluids in engineering are air and water and these values of Pr correspond to these two cases, respectively. This approach was established by Ostrach at NASA [19] in the early 1950s. It has subsequently been implemented by many leading researchers working in analytical thermosciences. Other examples of this approach, which have subsequently been used for numerical benchmarking, are the works of Takhar and Perdikis [20], Takhar and Ram [21]. Furthermore, even in some very recent numerical (and experimental) studies, Pr has been fixed, since when many parameters are involved e.g. Grashof number, Schmidt number etc, it is more worthwhile to fix the only parameter which is a “physical property” of a fluid i.e. Pr and to parametrically study other parameters. Vallis [22], one of the leading atmospheric fluid dynamicists in the world, of Princeton University’s Geophysical Fluid Dynamics Laboratory (GFDL) has as very recently expounded the benefit of studying single Prandtl number thermal convection flows. In [22] it is stated: “In most of our experiments we change the Rayleigh number by changing the diffusivity and viscosity, keeping the Prandtl number fixed.” Reference [22] used a single Pr = 10. Similarly other leading mathematicians working in analytical thermal convection have used a single Prandtl number. An example is the work of Siggers et al. [23].

The buoyancy ratio parameter, N, represents the ratio between mass and thermal buoyancy forces. When, there is no mass transfer and the buoyancy force is due to the thermal diffusion only. implies that mass buoyancy force acts in the same direction of thermal buoyancy force i.e. the buoyancy-assisted case, while means that mass buoyancy force acts in the opposite direction i.e. the buoyancy-opposed. The present results for the case of the ramp heating of the plate include the results of Chandran et al. [10] in the case of the absence of the buoyancy ratio parameter N.

The velocity profiles for different values of buoyancy ratio parameter (N) for both aiding and opposing effects of mass transfer are shown in figures 1 and 3 for both ramped and isothermal plate temperature boundary conditions in the presence of foreign mass and constant mass flux respectively. It is observed that the velocity increases in the presence of aiding flows whereas it decreases in the presence of opposing flows. Reverse flow is observed near the plate as the opposing buoyancy forces become dominant. It is also clear that the velocity near the plate is augmented with increasing time. Close observation of the curves for aiding flows from both figures reveals that the velocity is greater in the presence of foreign mass than that in the presence of constant mass flux. Foreign mass injection therefore accelerates the flow.

In figures 2 and 4 the velocity profiles are shown for different values of the Schmidt number (Sc) for aiding flows in the presence of foreign mass and constant mass flux respectively. It is observed that the velocity decreases with increasing Schmidt number. An increasing Schmidt number implies that viscous forces dominate over the diffusional effects. Schmidt number in free convection flow regimes, in fact represents the relative effectiveness of momentum and mass transport by diffusion in the velocity (momentum) and concentration (species) boundary layers. Smaller Sc values correspond to

lower molecular weight species’ diffusing e.g. Hydrogen in air (Sc ~ 0.16) and higher values to denser hydrocarbons diffusing in air e.g. Ethyl benzene in air (Sc ~ 2.0). Effectively therefore an increase in Sc will counteract momentum diffusion since viscosity effects will increase and molecular diffusivity will be reduced. The flow will therefore be decelerated with a rise in Sc as testified to by figures 2 and 4. It is also important to note that for Sc ~ 1, the velocity and concentration boundary layers will have the same thickness. For Sc < 1 species diffusion rate greatly exceeds the momentum diffusion rate and vice versa for Sc > 1. Inspection of figures 1 to 4 also indicates that the fluid velocity is greater in the case of an isothermal plate than for the case of ramped temperature at the plate. This is expected since in the case of ramped wall temperature the heating of the fluid takes place more gradually than in the isothermal plate case. This feature is important in for example achieving better flow control in nuclear engineering applications, since ramping of the enclosing channel walls can help to decrease velocities. The distribution of dimensionless surface shear stress i.e. skin-friction with time is depicted in figures 5 and 6 for different values of buoyancy ratio parameter (N) and Schmidt number (Sc) in the presence of foreign mass and constant mass flux respectively. It is observed that the skin friction is enhanced for the case of aiding flows but is reduced in the case of opposing flows. Our results also indicate that skin friction is suppressed with increasing species concentration for the case of aiding flows. From figures 5 and 6 we also infer that the skin friction is greater in the case of an isothermal plate than in the case of ramped temperature of the plate, in consistency with the discussion earlier for figures 1 to 4, since ramping decelerates the flow and lowers skin friction. It is also noted that for small values of t (i.e, t < 1), there is a sharp ascent in the skin friction in the case of an isothermal plate whereas the friction increases more gradually with increasing time for the case of ramped temperature at the plate. That is, the friction curves assume parabolic shapes for the time. Ramping therefore acts to stabilize the skin friction response and again this characteristic is important in industrial transient heat transfer control systems.

Figures 2, 4 and 5, 6 also include various computations for different Prandtl numbers, namely Pr = 0.71 and Pr = 7; the former corresponds to air, the latter to water. In all cases a noticeable reduction in skin friction is identified with an increase in Pr. Prandtl number quantifies the relative effectiveness of momentum and energy transport by diffusion in the velocity and thermal boundary layers. For Pr < 1, energy i.e. heat diffuses faster than momentum. For Pr > 1, momentum diffuses faster than heat. For the special case of Pr = 1, the momentum and thermal boundary layers will have the same thickness. In consistency with this we observe that in figures 2 and 4 velocity is decreased (profiles I and IV) and in figures 5 and 6 skin friction is reduced with an increase in Pr from 0.71 to 7 (profiles I and VI i.e. weakly buoyancy-aided flows with N = 0.2) since higher Pr fluids will possess greater viscosities and this will serve to reduce velocities, thereby lowering the skin friction.

The present analytical (Laplace transform) solutions provide other researchers with solid benchmarks for numerical comparisons. The authors have used this method in other articles where they have benchmarked numerical methods against analytical (Laplace transform) solutions

in the same article [24-28]. Various techniques have been used to confirm the accuracy of Laplace transform solutions in these complex multi-physical and geophysical fluid dynamics problems by the authors, including asymptotic analysis [24], complex variables [25,26] and electrical network simulation computational techniques based on the PSPICE software [27,28]. There is therefore great confidence in our solutions presented, based on Laplace transforms.

5. Conclusions

A general analytical solution for the problem of the unsteady free convection flow past an infinite vertical plate subjected to a ramped wall temperature in the presence of i) foreign mass and ii) constant mass flux at the plate has been determined without any restrictions. The dimensionless governing equations are solved by the Laplace transform technique. The effects of the governing thermophysical parameters i.e. buoyancy ratio parameter (N), Schmidt number (Sc), Prandtl number (Pr) and time (t) on the velocity field and skin-friction has been discussed. Our computations have shown that:

I) velocity increases in the presence of aiding flows and it decreases with opposing flows.

II) velocity decreases with increasing values of the Schmidt number for aiding flows.

III) velocity increases with increasing time.

IV) velocity is greater in the presence of foreign mass than with constant mass flux.

V) skin-friction is increased for assisted flows and diminished for opposing flows.

VI) skin friction is reduced with increasing species concentration for aiding flows.

VII) skin friction is reduced with an increase in Prandtl number for aiding flows.

The fluid velocity and skin-friction in the present case has also been compared with that for the case of an isothermal plate. For this scenario our solutions indicate that velocity and skin-friction are greater in the case of isothermal plate than in the case of ramped temperature at the plate. The present results are useful in further elucidating the important class of flows in which the driving force is induced by a combination of the thermal and chemical diffusion effects. Such results have immediate relevance in industrial thermofluid dynamics, transient energy systems and also buoyancy-driven geophysical and atmospheric vertical flows.

6. Acknowledgements

The authors wish to express their gratitude to the reviewer for his useful comments which have helped to improve the present article.
