Journal of Environmental Protection
Vol.07 No.11(2016), Article ID:71631,13 pages
10.4236/jep.2016.711131

Liming Characteristics of a High-Calcium Dry Flue Gas Desulfurization By-Product and a Class-C Fly Ash

Jason R. Burgess-Conforti1*, David M. Miller1, Kristofor R. Brye1, Lisa S. Wood1, Erik D. Pollock2

1Department of Crop, Soil, and Environmental Sciences, University of Arkansas, Fayetteville, AR, USA

2Stable Isotope Laboratory, University of Arkansas, Fayetteville, AR, USA

Copyright © 2016 by authors and Scientific Research Publishing Inc.

This work is licensed under the Creative Commons Attribution International License (CC BY 4.0).

http://creativecommons.org/licenses/by/4.0/

Received: September 19, 2016; Accepted: October 25, 2016; Published: October 28, 2016

ABSTRACT

Due to coal’s availability and low cost, coal combustion continues to be the United States’ primary energy source. However, coal combustion produces large quantities of waste material. Some coal combustion by-products (CCBs) have chemical and physical characteristics that make them potentially useful as soil amendments. The objectives of this study were to characterize a relatively new, high-calcium dry flue gas desulfurization (DFGD) by-product and compare its agronomic liming potential to a Class-C fly ash (FA) and reagent-grade calcium carbonate (CaCO3). Calcium carbonate equivalence (CCE), degree of fineness (DOF), and effective neutralizing value (ENV) for each CCB were determined using standard methods. The CCBs and CaCO3 were also incubated with an acidic (~4.5) clay sub-soil at application rates equivalent to 0, 0.5, 1, and 2 times the soil’s lime requirement and compared to an unamended control. Soil pH was then measured periodically during a 40-day incubation. The ENV of 79.4% for the DFGD by-product and 57.3% for the FA were comparable to those of commercially available liming materials, but were significantly lower (P < 0.05) than that of reagent-grade CaCO3. After 40 days of incubation at the 0.5× application rate, both CCBs raised the pH of the clay soil to only 5.0, while the CaCO3 raised the pH to 6.5. After 40 days at the 1× rate, all three materials had raised the soil pH to between 6.5 and 7.0, although the FA increased the soil pH more slowly than did the other two materials. At the 2× rate, both CCBs increased the soil pH to between 7.5 and 8.0, while the CaCO3 increased the soil pH to only 7.0. Both CCBs appear to be useful as soil liming materials, although care should be taken to avoid over-application, as this may make the soil too alkaline for optimum plant growth.

Keywords:

Coal Combustion By-Products, Agricultural Lime, Fly Ash, Flue Gas Desulfurization

1. Introduction

Coal combustion for energy production accounted for 39% of the 3.9 billion kilowatt- hours of electricity generated in the United States in 2014 [1] . Although natural gas is expected to eventually surpass coal as the primary fossil fuel source for electrical power generation in the United States, the ready availability and low cost of coal will likely allow coal to continue to be a major source of energy for approximately the next 35 years [1] . However, in addition to electricity, the coal-combustion process also produces large quantities of waste materials. In 2008, it was estimated that more than 123 million Mg of coal combustion by-products (CCBs) were produced, making CCBs the second largest waste stream in the United States behind municipal solid waste [2] . In 2007, only 44% of the CCBs generated in the United States were beneficially reused, which left 68 million Mg to be disposed of in landfills or surface impoundments [3] . The primary beneficial reuse fly ash is in concrete and concrete products, which represents 43% of beneficially reused fly ash. As of 2012 in the United States, 310 active on-site landfills and 735 on-site surface impoundments were used to dispose of CCBs that were not beneficially reused [4] .

Several types of waste products are produced from the combustion of coal for power generation. Fly ash (FA) is a CCB that is removed from flue gases by various types of particle-filtration equipment at coal-fired power plants. Fly ash consists of particles that have been fused into spherical, glassy, amorphous aluminosilicates and is classified into one of two categories depending on the composition of the coal being burned. Class-C FA has a high calcium (Ca) concentration (25% to 35%) and is derived from the burning of lignite and subbituminous coals, whereas Class-F FA has a low Ca concentration (0% to 10%) and originates from the burning of anthracite and bituminous coals [5] . Class-C FA is often referred to as “high-lime ash” and is a common by-product of coal- fired power plants burning low sulfur coals from Wyoming and Montana [6] .

A more recently produced waste material is flue gas desulfurization (FGD) by-pro- ducts which result from emissions-control processes that inject a calcium sorbent into the flue gases to trap and remove sulfur dioxide (SO2) from the emissions streams. Dry FGD (DFGD) systems often remove SO2 and FAs simultaneously, resulting in a by- product that is a mixture of FA, unreacted sorbent, calcium sulfite (CaSO3ž½H2O), and calcium sulfate (CaSO4ž2H2O) [7] . In response to recent environmental regulations, coal-fired power plants have combined conventional desulfurization processes with the injection of activated carbon to remove mercury (Hg) (personal communication, Mark Cantrell, Arkansas Electric Power, 2016). This new emissions-control process has resulted in the generation of new DFGD by-products that may be chemically dissimilar from DFGD by-products produced previously.

Because they contain unspent sorbent, DFGD by-products are typically alkaline and have the potential to be used as substitutes for agricultural lime. Dry FGD by-products containing Class-C FA can have particularly high concentrations of Ca and are often described as high-Ca DFGD by-products. The growing concern regarding long-term storage of CCBs has led to increased interest in finding beneficial uses for these by- products. High-Ca CCBs may have potential for use in agriculture as a liming material, which can lead to a reduction in the volume of CCBs destined for disposal in landfills and surface impoundments, while helping to ameliorate soil acidification.

It is estimated that 25% to 30% of the world’s soils are acidic enough to cause reductions in crop yields, decreased bioavailability of essential plant nutrients, and increased availability of potentially phytotoxic elements such as aluminum (Al) and manganese (Mn) [8] . Acidification of soils may be caused by a variety of processes including acidic precipitation and leaching of basic cations, but is most often caused by nitrification, the process whereby ammonium (NH4+) is oxidized to nitrate (), which yields protons (i.e., H+ ions) [9] . Regular application of liming materials, such as lime (CaCO3), burnt lime (CaO), hydrated lime [Ca(OH)2], and dolomitic limestone [CaMg(CO3)2], have been used historically to raise soil pH back to desired levels after years of acidification has lowered the soil pH beyond the minimum desired pH range for optimal plant growth. The presence of highly soluble CaO and Ca(OH)2 in Class-C FA and DFGD by-products enhances the potential for increasing soil pH above 7 and neutralizing soil acidity beyond the site of incorporation [10] .

Considering that DFGD by-products are a relatively new CCB that has been minimally studied, the objectives of this study were to characterize a high-Ca DFGD by- product and compare its agronomic liming potential to a Class-C FA and reagent-grade CaCO3. It was hypothesized that due to the high Ca concentrations of Class-C FAs, the coal by-products would be as effective as CaCO3 at increasing soil pH at the 1× application rate, and more effective at the 2× application rate.

2. Materials and Methods

2.1. Initial Soil Collection and Characterization

A grab sample of soil was collected from the 122 to 155-cm depth interval of a Pickwick silt loam (fine-silty, mixed, semiactive, thermic Typic Paleudults) [11] located under a Loblolly pine (Pinus taeda) plantation at the University of Arkansas Agricultural Research and Extension Center in Fayetteville, Arkansas. This soil was chosen for its acidic pH (~4.5) and high clay content. The soil was air-dried at 21˚C for 7 d and ground to pass a 2-mm sieve. Soil texture was determined to be clay (i.e., 37% sand, 20% silt, 43% clay) using a modified 12-hr hydrometer method [12] . The liming requirement of the soil (to achieve pH 7.0) was measured using the Shoemaker, Mclean and Pratt (SMP) buffer method [13] and was determined to be 34.9 Mg∙ha−1. Initial soil pH was determined potentiometrically using a 1:1 (v:v) soil:0.01M CaCl2 slurry.

2.2. Liming Reagents

The three liming materials used in this experiment were reagent-grade CaCO3, a Class- C FA, and a high-Ca, DFGD by-product. The Class-C FA was collected by an electrostatic precipitator and a silo baghouse from the Flint Creek Power Plant in Benton County, Arkansas [14] . The DFGD by-product was generated by a dry scrubber using an Alstom Novel Integrated Desulfurization design at the John W. Turk Power Plant in Hempstead County, Arkansas (personal communication, Mark Cantrell, 2015). Both power plants burn subbituminous coal from the Powder River Basin in Wyoming (personal communication, Mark Cantrell, Arkansas Electric Power, 2015). The John W. Turk power plant utilizes calcium hydroxide [Ca(OH)2] as the sorbent in the desulfurization process (personal communication, Mark Cantrell, Arkansas Electric Power, 2015). Trace element concentrations of the Class-C FA and DFGD by-product were determined by inductively coupled plasma mass spectrometry (ICP-MS) following a microwave digestion in concentrated HNO3.

2.3. Effective Neutralizing Value

The effective neutralizing value (ENV) of the liming materials was calculated using the degree of fineness (DOF) and the CaCO3 equivalence (CCE). The DOF was determined in triplicate by passing each of the three liming materials through 20-, 60-, and 100- mesh sieves (0.84-, 0.25-, and 0.15-mm mesh size, respectively) and calculating the percentage of material by weight that passed through each sieve relative to the 20 g of initial material. Sieving of the material was conducted in accordance with ASTM C110-14 by manually sieving in a lateral and vertical motion, while occasionally jarring the sieve, for a total of 10 minutes [15] . Calcium carbonate equivalence was determined potentiometrically using an Orion 710a pH meter and an Orion 9107bn pH probe (Thermo Fisher Scientific, Waltham, MA) by adding 100 mL of 1N hydrochloric acid (HCl) to 2.0 g of liming material and back-titrating to pH 7.0 with 1N sodium hydroxide (NaOH) in accordance with ASTM C25-11 [16] . The ENV was calculated using the following equation:

(1)

where A is equal to 0.4 times the percentage of particle passing a 20-mesh sieve minus the percentage of particle passing a 60-mesh sieve, B is equal to 0.8 times the percentage of particle passing a 60-mesh sieve minus the percentage of particle passing a 100-mesh sieve, and C is equal to 1.0 times the percentage particle passing a 100-mesh sieve.

2.4. Incubation Study

Samples were prepared in triplicate for each of the three liming materials (i.e., reagent-grade CaCO3, FA, and DFGD) and an unamended control that were destructively sampled at nine sampling times (i.e., 0, 5, 10, 15, 20, 25, 30, 35, and 40 d of incubation). Therefore, there were a total of 270 samples prepared initially for incubation (3 liming materials × 9 time points × 3 rates × 3 replicates + 1 control × 9 time points × 3 replicates). Liming materials were added to 20 g of air-dry soil in 50-mL centrifuge tubes at application rates equivalent to 0× (control), 0.5×, 1×, and 2× (0, 0.175, 0.35, and 0.7 g, respectively) the soil’s SMP buffer liming requirement. The tubes were thoroughly mixed by shaking for 5 min in a side-to-side shaker. Following mixing, samples were adjusted to a gravimetric moisture content of 22%, based on the estimated field moisture capacity using deionized water [17] . Soil pH was measured by adding 20 mL of 0.01 M CaCl2 to 20 g of soil and mixing for 5 min in a side-to-side shaker. The pH of the resulting slurry was measured within 1 min of shaking the mixture. Soil pH measurements were made on triplicate samples every 5 days for the duration of the 40-d incubation period.

2.5. Statistical Analyses

A one-factor analysis of variance (ANOVA) was conducted using the PROC MIXED procedure in SAS (version 9.3; SAS Institute Inc., Cary, NC) to evaluate the effect of liming material on their liming characteristics (i.e., DOF, CCE, and ENV). In addition, a three-factor ANOVA was conducted using the PROC MIXED procedure in SAS to evaluate the effects of liming material, rate, time, and their interactions on soil pH response. When appropriate, means were separated by least significant difference (LSD) at the α = 0.05 level.

3. Results and Discussion

3.1. Initial Coal Combustion By-Product Characterization

The mean pH of the three liming reagents used was 10.6, 12.3, and 8.4 for the DFGD by-product, FA, and reagent-grade CaCO3, respectively (Table 1). Both the DFGD by- product and Class-C FA had elevated concentrations of trace elements which may warrant concern when being evaluated as a soil amendment. As a result of the high concentration of trace elements and soluble salts, the EC was 2.41 and 2.73 mS∙cm−1 for the DFGD by-product and Class-C FA, respectively (Figure 1). The EC of the reagent- grade CaCO3 was 0.042 mS∙cm−1. Continuous application of either the DFGD by-product or Class-C FA may cause an increase in soil EC and limit growth for plants that are sensitive to saline soils [10] .

3.2. Liming Characteristics

All three liming characteristics evaluated in this study (i.e., CCE, DOF, and ENV) differed somewhat among liming materials. The CCE of the DFGD by-product (84.4%) was lower (P < 0.05) than that for reagent-grade CaCO3 (100%), while CCE for Class-C FA (60.3%) was also lower (P < 0.05) than that for the DFGD by-product (Figure 1). In contrast to CCE, DOF for the DFGD by-product and Class-C FA were similar to one another (P > 0.05), averaging 94.1 and 95.1%, but both were lower (P < 0.05) than that for reagent-grade CaCO3 (Figure 1). Similar to CCE, but in contrast to DOF, ENV of the DFGD by-product (79.4%) was lower (P < 0.05) than that for reagent-grade CaCO3 (100%), while CCE for Class-C FA (57.3%) was also lower (P < 0.05) than that for the DFGD by-product (Figure 1). The low ENV for the Class-C FA can be attributed to the low CCE of 60.3%. The DFGD CCE of 84.4% was similar to the values reported by Kost

Figure 1. Calcium carbonate equivalence (CCE), degree of fineness (DOF), and effective neutralizing value (ENV) of reagent grade CaCO3, a high-Ca dry flue gas desulfurization by-product, and a class-C fly ash. Bars of the same color with different letters are significantly different (P < 0.05).

Table 1. Mean chemical characteristics of a high-Ca dry flue gas desulfurization by-product from the John W. Turk Power Plant in Hempstead County, Arkansas and a Class-C fly ash from the Flint Creek Power Plant in Benton County Arkansas. The CaCO3a used in this experiment was reagent grade.

a. CaCO3 pH = 8.44; EC = 0.042 mS∙cm−1; b. pH was measured in a 1:1 0.01 M CaCl2:solid slurry; c. EC was measured in a 2:1 DI water:Reagent slurry.

et al. [7] who reported a CCE range of 41.6% to 97.7% for spray-dryer DFGD by- products. Schlossberg et al. [18] stated that CCEs of Class-C FAs can be as high as 60%, which is similar to the CCE of the Class-C FA examined in this experiment. Although CCE and ENV of the DFGD by-product were lower than that for reagent-grade CaCO3, most commercially available liming materials have ENVs ranging between 70 and 90, which is a range that includes the mean measured ENV for the DFGD by-product evaluated in this study [19] .

3.3. Incubation Study

As expected, soil pH differed (P < 0.001) among liming material-application rate treatment combinations over time throughout the 40-d incubation period (Table 2). For all material-rate combinations, with the exception of the unamended control, soil pH generally sharply increased from day 0 to day 20, followed by a period of either a more gradual soil pH increase or no further increase from day 20 to day 40. The greatest differences among treatment combinations occurred among liming materials over time within an application rate.

Within 1 min after shaking the soil of the unamended control treatment, initial soil pH averaged 4.3 (Figure 2; Table 3). Soil pH in the unamended control remained virtually unchanged throughout the entire duration of the 40-d incubation period (Figure 2; Table 3). Within 5 d of incubation, the pH of soil receiving CaCO3 at the 0.5× application rate was significantly greater (5.8) than the pH of soil that was incubated with the Class-C FA or DFGD by-product (4.6) (Figure 2; Table 3). After 10 d of incubation, the pH of soil receiving the 0.5× rate of CaCO3 was significantly greater (6.3) than the pH of the DFGD- (5.0) and the FA-treated soil (4.7). From day 20 to day 40, soil pH did not differ between the DFGD and FA-treated soils. After 40 d of incubation, the pH of soil receiving the three liming materials had increased (P < 0.05) from a pH of 4.3 in the unamended control to 6.7, 5.0 and 4.8 for the reagent-grade CaCO3, DFGD by-product, and FA treatments, respectively.

Table 2. Analysis of variance summary of the effects of liming material (i.e., product), rate, and time (i.e., days into incubation), and their interactions on soil pH after 40 days of incubation in a clay soil.

Figure 2. Soil pH response after incubation at 0.5×, 1×, and 2× the Shoemaker-Mclean-Pratt (SMP) liming requirement with reagent-grade CaCO3, Class-C fly ash, and a high-Ca dry flue gas desulfurization (DFGD) by-product over a 40-day period.

Table 3. Mean pH of soil incubated with reagent-grade CaCO3, Class-C fly ash (FA), and a high- Ca dry flue gas desulfurization (DFGD) by-product at rates equivalent to 0.5×, 1×, and 2× the Shoemaker-Mclean-Pratt (SMP) lime requirement over a 40-day period.

aMeans followed by a different letter within a row are significantly different (P < 0.05).

At the 1× application rate, the DFGD by-product and FA were more effective at raising soil pH than at the 0.5× application rate. After 5 d of incubation, the pH of the soils incubated with the DFGD by-product and FA at the 1× application rate were greater (P < 0.05) than those in the soils receiving the same amendments at the 0.5× application rate (Figure 2; Table 3). After 10 d of incubation, and for the remainder of the 40-d incubation period, there was no difference in soil pH between reagent-grade CaCO3-amended soil and DFGD by-product-amended soil at the 1× application rate. Between 10 and 30 d of incubation at the 1× rate, soil pH was lower (P < 0.05) in the FA treatment than in the reagent-grade CaCO3 and DFGD by-product treatments, which did not differ. Soil pH did not differ among the three treatments at the 1x rate after 30 d of incubation. After 40 d of incubation at the 1× application rate, soil pH had increased (P < 0.05) from 4.3 in the unamended control to 7.0, 7.0, and 6.7 in the reagent-grade CaCO3, DFGD by-product, and FA treatments, respectively, which did not differ from one another. Compared to the 0.5 and 1× rates, soil pH responses were even more pronounced for the 2× application rate. After 10 d of incubation at the 2× rate, the pH of the soil that was amended with either the DFGD by-product or FA was greater (P < 0.05) than that for the soil amended with the reagent-grade CaCO3 (Figure 2; Table 3). From day 10 to day 40, the pH of soil incubated with either the Class-C FA or DFGD by-product at the 2× application rate was greater (P < 0.05) than the pH of soil incubated with reagent-grade CaCO3. After 40 d of incubation, the pH of the soils receiving the three liming materials at the 2× application rate had increased from 4.3 in the unamended control to 7.3, 8.0, and 8.0 for the reagent-grade CaCO3, DFGD by-product, and FA treatments, respectively. The pH of soils incubated with either the Class-C FA or DFGD by-product was greater (P < 0.05) than the pH of soil incubated with reagent- grade CaCO3, but did not differ from each other.

Both CCBs evaluated in this study have potential for use as soil liming materials. Calcium carbonate is relatively insoluble in water and the solubility of CaCO3 decreases rapidly above pH 6.0 [20] . Once the soil pH exceeds 7.0, CaCO3 effectively becomes insoluble. This explains why the pH of soil amended with CaCO3 at the 2× application rate was not greater (P > 0.05) than that of the soil amended with CaCO3 at the 1x application rate. Calcium oxide (CaO) and Ca(OH)2 have greater CCEs and continue to be soluble at greater pHs than CaCO3, resulting in greater equilibrium soil pHs. The large concentrations of CaO and Ca(OH)2 typically present in the Class-C FA and DFGD by-product may explain why both liming materials were able to raise soil pH to 8.0 when amended at the 2× application rate.

The ability of the FA and DFGD by-product to raise soil pH to 7 over approximately the same time period as CaCO3 suggests that these by-products may be viable alternatives to traditional liming materials. The results of this experiment are similar to those reported in previous experiments where different CCBs were used. Punshon et al. [21] mixed a weathered FGD by-product with an acidic Paleudult (pH 5.4) at several application rates and reported an increase in soil pH from 5.5 to 8.1 in soil amended with by-product at application rates of 168 and 224 Mg∙ha−1. Adriano et al. [6] mixed a Class-F (i.e., low calcium) FA with an acidic Udifluvent (pH 4.9) at an application rate of 1120 Mg∙ha−1 and reported an increase in soil pH to 6.45. McCarty et al. [22] incubated soil with bed ash, FA, limestone-injection multistage burner (LIMB) residue, spray dryer residue (SDR), and CaCO3 with an acidic Hapludult (pH 4.2) at application rates ranging up to 22.4, 22.4, 22.5, 89.6 and 18.0 Mg∙ha−1 for the bed ash, LIMB, SDR residue, FA and CaCO3, respectively. The pH of the soils at the largest application rates were 8.0, 7.7, 7.1, 7.7 and 7.8 for the bed ash, LIMB residue, SDR residue, FA, and CaCO3, respectively. The ability for the CCBs tested to increase soil pH in that experiment was in directly related to their respective CCEs [22] . When the means of soil pH were adjusted for covariance of CCE, there was no difference between the FA and CaCO3.

In this study, both the Class-C FA and DFGD by-product were able to raise the soil pH to 8.0 when applied at the 2× application rate. Most crops grow best in soils with a slightly acidic pH and can become stressed (i.e., due to a nutrient limitation or toxicity) if the soil pH is too alkaline. Therefore, caution must be exercised when using CCBs to avoid over-application and raising the soil pH so high that plant growth and productivity are negatively affected.

In addition to the ability to neutralize soil acidity at the surface, DFGD by-products contain large concentrations of CaSO4∙2H2O (i.e., gypsum), which has been shown to ameliorate subsoil acidity. Sumner et al. [23] reported a 20% decrease in exchangeable Al at a depth of 105 cm following surface application of gypsum at a rate of 10 Mg∙ha−1. Gypsum-amended soil had a greater Ca saturation in the subsoil (i.e., the 5- to 105-cm depth interval) than the unamended control. Wendell and Ritchey [24] observed a similar trend in acidic soil columns amended with a high-Ca DFGD by-product. Leachate- Al concentrations were greater than that in the unamended control as a result of DFGD by-product addition, resulting in a decrease in the soil’s exchangeable Al percentage [24] .

Another possible use for these CCBs is in the reclamation of soils that have been disturbed by surface mining. Surface mining is a process can that cause severe soil acidification resulting from the exposure of Fe-sulfides in overburden materials [25] . Because acid mine lands are often very acidic (pH < 4.50), there is potential for large-scale use of alkaline CCBs to neutralize overburden acidity without creating alkaline soils. By increasing soil pH, the solubility and mobility of potentially toxic elements, such as arsenic, can be reduced [26] . Stehouwer et al. [25] and Stehouwer et al. [27] examined the effects on element solubility and mobility, as well as plant growth by amending minespoil material with DFGD by-products in a series of greenhouse studies. When applied at rates ranging from 30 to 120 g kg−1, fescue (Festuca arundinacea) growth improved likely due to the increase in tissue concentrations of Ca, Mg, and S. At rates exceeding 120 g kg−1, the soil became too alkaline and cementation of the soil occurred as a result of the formation of ettringite [(Ca6Al2(SO4)3(OH)12∙26 H2O)]. With increasing application rate of the DFGD by-products, there was an increase in leachate pH, EC, dissolved organic C, Ca, Mg, and S. The concentrations of leachate As, B, Cu, Ni, and Se varied depending on the concentration of DFGD by-product and spoil type. Utilizing CCBs as a mine-spoil amendment may be more desirable than as an agronomic soil amendment because of the potential for plant uptake of trace elements by agronomic crops.

4. Conclusions

Each year, millions of megagrams of CCBs are disposed of in landfills and surface impoundments, which increases the likelihood of accidental releases to the environment. Certain CCBs, such as Class-C FAs and DFGD by-products, possess physical and chemical properties that make them potentially useful as soil liming materials. If a local source is available, CCBs may be a usable alternative to conventional agricultural liming materials for mitigating soil acidity in a manner that is economically viable. The presence of gypsum in DFGD by-products provides the additional benefit of reducing subsoil acidity by acting as a source of Ca2+ ions and lowering levels of exchangeable Al3+. However, the presence of trace elements and heavy metals warrants caution if CCBs are used as a soil amendment.

The results of this experiment support the hypothesis that when CCBs, specifically Class-C FA and DFGD by-product, are added to an acidic subsoil at a rate equivalent to the SMP buffer lime requirement, the soil pH after 40 d would be similar to the pH in reagent-grade CaCO3-amended soil. Results also supported the hypothesis that the pH of soil incubated with the DFGD by-product and Class-C FA at 2× the SMP buffer lime requirement would be greater than soil incubated with reagent-grade CaCO3. This experiment demonstrated that the relatively new DFGD by-product has similar liming characteristics to reagent-grade CaCO3 and a Class-C FA, which may provide a viable alternative use of DFGD by-product as a soil amendment and liming material and would diminish the need to dispose of these materials in landfills and surface impoundments.
