New Voltage Mode Sinusoidal Oscillator Using Voltage Differencing Transconductance Amplifiers (VDTAs)

NishaWalde^{*}, Syed Naseem Ahmad

Department of Electronics & Comm. Engineering, JamiaMilliaIslamia, New Delhi, India

Email:^{*}nisha.walde1@gmail.com,snahmad@jmi.ac.in

Copyright © 2015 by authors and Scientific Research Publishing Inc.

This work is licensed under the Creative Commons Attribution International License (CC BY).

Received 19 June 2015; accepted 15 August 2015; published 19 August 2015

ABSTRACT

The purpose of this paper is to introduce a new electronically controlled voltage mode sinusoidal oscillator (VMSO) using Voltage Differencing Transconductance Amplifiers (VDTA).The proposed circuit provides electronic control of*ω _{0}* and independent condition of oscillation (CO). It is found that the oscillator works very satisfactorily and pure sinusoidal waveforms are available at the outputs. The PSPICE simulation confirms the theoretical results. The proposed oscillator circuit employs only two VDTAs, along with two grounded capacitor and single grounded resistor. The circuit exhibits low active and passive sensitivities for

*ω*. Simulation results are obtained by using PSPICE software with TSMC CMOS 0.18 um process parameters.

_{0}**Keywords:**

Voltage Differencing Transconductance Amplifier (VDTA), Voltage-Mode Circuit, Oscillator

1. Introduction

In recent years the focus has been on the design of various applications based on advanced analog building blocks [1] -[4] . Sinusoidal oscillators find wide applications in communication engineering, electronic instrumentation and control systems [5] [6] . The voltage differencing transconductance amplifier (VDTA) is an active versatile building block used in the realization of analog signal processing circuits and analog wave generation. It is also attractive due to its capability of adjusting the output current gain.

However, these circuits suffer from

・ Lack of electronic adjustability [7] .

・ Excessive use of passive elements, especially external resistors.

・ Use of a floating capacitor, which is not convenient to further fabrication in IC.

・ Oscillation conditions (CO) and oscillation frequencies cannot be independently controllable.

Various filters and oscillators are designed using active building blocks such as CFTAs[8] [9] ,CCCFTAs[10] ,CDTA,VDTA,CFA,CC-II [11] -[18] .

The purpose of this paper is to present new voltage mode sinusoidal oscillator by using two VDTAs, two grounded capacitors and one resistor. PSPICE simulation results are provided, which verify the workability of the proposed circuit. The resulting circuit is low-power and provides independent control of the condition of oscillation (CO) and frequency of oscillation (FO). The important feature of VDTA is that this new element exhibits two different values of transconductances so that several applications such as oscillator, filters, inductance and FDNR (frequency dependent negative resistor) simulator can be realized with a single active block employing one or two capacitors. One more important feature is that this block can be used easily at transconductance mode applications such that the input terminals is voltage and output terminals is current. The proposed circuit employs minimum number of passive and active components. The use of additional VDTA facilitates the achievement of independent control of ω_{0}, which is an attractive feature of the circuit.

2. Circuit Description

The Voltage Differencing Transconductance Amplifier (VDTA), whose schematic symbol is shown in Figure1, consists of an input current follower that transfers the input current to the z terminal and an output transconductance amplifier stage, which is used to convert the voltage at the zterminal into output currents. Relations between the individual terminals of VDTA can be described by the following hybrid matrix:

(1)

where is transconductance gain of the VDTA which is given by Equations (2) & (3). Internal construction of VDTA used for simulation is shown in Figure 2.The introduced circuit employs two transconductances.Input and output transconductances parameters of VDTA element in the circuit are determined by the transconductance of outputs transistors. It can be approximated as

(2)

(3)

where is the transconductance value of i^{th} transistor defined by

, (4)

Figure 1.The VDTA schematic symbol.

Figure 2.Internal construction of VDTA using CMOS used for simulation.

is (i = n, p) the mobility of the carrier for NMOS (n) and PMOS (p) transistors, is the gate-oxide capacitance per unit area, W is the effective channel width,L is the effective channel length and is bias current of i^{th} transistor.The proposed VMSO using VDTA [18] is shown in Figure 4.It consists of 2 VDTAs, 2 grounded capacitors and one resistor.

3. Proposed Circuit Realization of VMSO Using Voltage Differencing Transconductance Amplifier (VDTA)

The oscillator is designed by cascading an inverting second order low-pass filter and the lossless integrators as shown in Figure 3.From block diagram as shown in Figure 3, we obtain the characteristic equation of a sinusoidal oscillator as

(5a)

Hence, from Equation (5a), the condition of oscillation (OC) and frequency of oscillation (FO) can be written as

(5b)

and

(5c)

From Equation (5a), if a = c, the oscillation condition and oscillation frequency can be adjusted independently, i.e. the oscillation condition can be controlled by b and k, while the oscillation frequency can be tuned by a. The proposed voltage mode sinusoidal oscillator using VDTA is shown in Figure 4. The frequency of oscillation (FO) and condition of oscillation (CO) are found to be

If

(6)

(7)

From the above equations it is clear that condition of oscillation can be set by R_{1},. Frequency of

Figure 3. Block diagram for the design of proposed oscillator.

Figure 4.ProposedVMSO using VDTA.

oscillation is controlled independently by which is independent of CO. The voltage mode transfer function obtained from Figure 4 is

(8)

Therefore, the proposed circuit provides two voltage mode sinusoidal oscillations across output simultaneously.

4. Non Ideal and Sensitivity Analysis

The FO and CO for the circuit shown in Figure 5 are given as:

(9)

(10)

From Figure 5, it shows that parasitic capacitances C_{p} andC_{z} are in parallel with the external capacitances C_{1} and C_{2} respectively. Therefore, the influence of the parasitic capacitances can be eliminated easily by reducing the values of external capacitances. If is infinite, the frequency of oscillation and condition of oscillation are independently tunable even under the influence of VDTA parasitic. The effect of changes in active and passive element values is determined by evaluating sensitivity coefficients which are found to be

(11)

Therefore, all the active and passive sensitivities of ω_{0} are low. The non ideal equivalent circuit of proposed oscillator under the influence of VDTA parasitic [14] is shown inFigure 5.

5. Simulation Results

The performance of the proposed voltage mode sinusoidal oscillator circuit in Figure 4has been verified by PSPICE simulation results. The PMOS and NMOS transistors have been simulated by respectively using the parameters of a 0.18µm TSMC CMOS technology [11] [18] .The aspect ratios of PMOS and NMOS transistors are indicated in Table 1.The circuit was biased with ±0.9V power supply voltage, ,

. The transconductance values of VDTA are

and the parasitic capacitance at the Z terminal is specified as C_{p} = 0.15pF.The values of the capacitors were chosen as: and.In Figure 6, time domain response of the proposed VMSO using VDTA is shown using PSPICE 16.3 which confirms the validity of design equations of oscillator shown in Equations (6)and (7). Frequency of oscillation was found to be f_{0} = 15.56MHz.

Figure 5.Non ideal equivalent circuit of proposed VMSO.

Figure 6.Time domain response of the proposed VMSO using VDTA.

Table1.Dimensions of the transistors.

6. Conclusion

In this paper, a new VMSO using VDTAs (Voltage Differencing Tranconductance Amplifier) is presented as shown in the PSPICE. The circuit is realizedby using two VDTAs, two grounded capacitors and one resistor. The circuit has the features of low active and passive sensitivities, low voltage supply and large bandwidth. It has low-input and high-output impedances and is also convenient for electronic controllability through transconductance gain g_{m} of VDTAs.
