Generalization of the Thermal Dose of Hyperthermia in Oncology

Gyula Vincze, Oliver Szasz, Andras Szasz*

Szent István University, Gödöllő, Hungary

Email: *Szasz.Andras@gek.szie.hu

Copyright © 2015 by authors and Scientific Research Publishing Inc.

This work is licensed under the Creative Commons Attribution International License (CC BY).

http://creativecommons.org/licenses/by/4.0/

Received 3 July 2015; accepted 25 October 2015; published 28 October 2015

ABSTRACT

Hyperthermia has been a modality to treat cancer for thousands of years. During this time, intensive efforts are concentrated on determining the dose of the proper treatment, but the dominantly in vitro induced cellular death does not provide enough confidence for the clinical dosing. The cell-death by heat-monotherapy applications in laboratory experiments is difficult to apply in the complementary therapies in clinical applications. The newly developed nanotechnologies offer completely new possibilities in this field as well. Modulated electro-hyperthermia (mEHT, trade- name Oncothermia) is a nanoheating technology that has selective effects on membrane rafts and on the transmembrane proteins. This effect is thermal. The thermal action is in nanoscopic range which makes the phenomenon special. Our objective is to show the dose concept on this emerging method.

Keywords:

Thermal Dose, Oncothermia, Nano-Targeting

1. Introduction

Hyperthermia, as a treatment in oncology, has a thousand-year tradition [1] . It has tremendous fluctuations in its applications and trusts in its efficacy [2] . This addresses serious questions: “Where are we?” [3] , “Where are we going?” [4] . One of the central problems of the hyperthermia in oncology is the dosing [5] . The problem of the dose is very general due to that the temperature is the central parameter of this heating method. However, the focusing of the energy-absorption doesn’t mean the focus of the temperature too, because the heat spread by time is forced mainly by a very effective heat-exchanger: the blood-flow. Our objective in this paper is to clarify the dosing which is based on the in vitro experiments of necrotic distortion fitting it to the Arrhenius plot. We generalize this Arrhenius based on dosing, including the direct SAR, from the selectively targeting electric field.

Oncologic hyperthermia massively uses external heat transfer from the outside towards the inside. The classical solution is based on heat-conduction from the skin. The heat-conduction is robustly increased by heat- convection of the induced intensive blood-flow in the skin.

The whole-body heating processes definitely follow this way, using the blood-flow in the subcutaneous capillary-bed, transferring the absorbed energy all over the body [6] . The method has many early descriptions [7] - [10] ; but the dominant systemic hyperthermia method is based on the infra-red radiation by multi-reflecting filtering [11] [12] or by water-filtering [13] [14] .

Another type of oncological hyperthermia is not systemic. Its volume ranges widely: from regional to local, from a part of the body to a nanoscopic targeting.

Their typical parameters are summarized in Table 1.

Thermodynamically, the systemic and loco-regional treatments differ from their heat-flow direction between the tumor and its neighborhood. The blood-heating techniques pump heat-energy from blood to the tumor, while the blood works opposite in the loco-regional heating, cooling the anyway heated tumor because it remains in body temperature. The physiological limits are also different. While the systemic heating is limited at 42˚C, the local one has no limit in the tumor. The temperature limit of loco-regional treatment is only keeping the healthy vicinity of the tumor safe, as well as the skin, where the energy is pumped into the body.

Technically, the local deep-focusing is a great challenge. Most of the local treatments with deep focusing possibility use some kind of electromagnetic energy-absorption. Multiple new techniques are devoted to deliver the proper energy for heating [15] .

One of the earliest non-invasive deep heating is the simple inductive way, which is typically achieved by the induction of eddy-currents in the body [16] -[18] . This method has low efficacy, but its non-invasive penetration easily crosses over the body, and its focusing or selective orienting is not possible. Other loco-regional electromagnetic heating methods work by radiative [19] -[21] , or by capacitive [22] -[24] , technical solutions. These non-invasive electromagnetic heating solutions use a wide range of frequencies, having definitely different effects and penetration depth to the body [14] . However, in most of the cases, the limited penetration depth is enough for effective deep heating [25] .

Interestingly, the trend of the modern hyperthermia is directed to the smaller targets. Their intensive locality is somehow similar in this character to the original galvanic methods. The typical high-energy focusing can be solved by microwaves [26] or very locally by interstitial heating invasively [27] . It delivers heat to the tumor mass directly using a needle providing high frequency. Typically, this type of therapy is applied in an image guided way. These ablation methods work by typical burn-necrosis basis, and the energy is typically provided by impedance-heating with minimally invasive electrode insertion; there is no heat-flow through the skin. Some typical applications are for liver [28] , lung [29] [30] , and breast [31] . Numerous ablative, interstitial hyperthermia combined with local irradiation are applied for brain tumors [32] -[35] , and implant applications [36] [37] , and also combined with laser techniques [38] [39] .

Some modern laser ablative techniques work with ultrafast pulses with ultra large energy-density flow. Depending on the pulse-duration, it can be a few 100 W/cm2 and in nano-seconds can go to 107 - 108 W/cm2 [40] , but the provided energy altogether reaches its maximum at a few tenths of watts. Their application for liver [41] , [42] , is common. This emerging technology, together with the electroporation techniques, has been shifted more-and-more to become the tool of surgery, applied it on intraoperative way, or applied by interventional radiology, isolated a little bit from the general hyperthermia practices.

The photodynamic therapy (PDT) [43] , uses heating of the micro-targets like photosensitized liposomes or other photosensitizers [44] , by infrared or visible radiation. The micro-absorption of the heat assists targeted

Table 1. Typical physical parameters of the basic hyperthermia-treatment categories.

drug-delivery, combined with the heat development. This could non-invasively treat shallow-seated tumors, only the light-source has to be introduced invasively (mostly with optical fibers) for heating in depth.

There is a selective tumor targeting applied by temperature sensitive liposome-jacketed drug-delivery [45] , as well as the drug delivery with temperature activated nanoparticle complexes [46] . PDT can be applied with nanoparticle administration too [47] , when the particles are the real absorbers of the energy. The method is based on artificially set nanoparticle concentration in the targeted volume [48] [49] .

The disadvantage of the weak coupling of magnetic fields in direct inductive heating turns to an advantage when artificial absorbers are applied. The energy absorption from the magnetic field is practically limited to these magnetic absorbing centers, orienting the SAR where the artificially inserted magnetic materials are. These materials will solely react with the electromagnetic fields, and their absorbed energy will be the source to heat up their surroundings. The energy absorption could be absolute, precisely guided by the place of these absorbers. In order to improve the magnetic energy absorption within the target tissue, magnetic materials, such as micro-particles [50] and ferrite rods [51] , are usually injected into the targeted area [52] , orienting the field to the particles and massively absorbing the incident energy. The emerging application of magnetic treatments is started by the nanoparticle magnetic suspensions [53] and other magnetic liquids.

Definite shifts of hyperthermia techniques have been made in the last decade, showing a trend to nanotechnology [54] . Applications of various nanoparticles for combined hyperthermia are new, emerging methods in oncology [46] . In this method the nanoparticles (which are usually administered in a suspension [53] ) are small heat-absorbers. They are selectively heated up by an outside photo-energy or magnetic field [55] , which acts exclusively only on these nanoparticles. The trick here is the accurate targeting of the heat-absorption. The overheated nanoparticles soon give their heat-energy to their neighborhood and heatup the complete lesion in their vicinity. A great deal of energy is pumped into these nanoparticles being able to heatup the complete mass, containing a large amount of electrolytes. However, most of the electrolytes are uselessly heated up because the heat has to be concentrated on the tumor cells and exclusively on their membranes to damage them. This request needs a higher preciosity addressing the nanoparticles selectively on the surface of the tumor cells, which can be made by antibody-nanoparticle conjugates [56] . It releases the therapeutic targets at the connected malignant cells while minimizing off-target side effects. When the delivering nanoparticle―which is especially bonded to the membrane of the malignant cell―is heated up by an outside field, it could have a double effect: damaging the membrane by heat and/or release the drug that was delivered to the target [57] . Most of the nanoparticle hyperthermia effects are subcellular, inducing intracellular action [58] ; however, the efficacy of this treatment is debated [59] .

Based on nanotechnology, a new, emerging way is connected to various immune actions [60] , which could be applied in loco-regional hyperthermia, too. This transforms the modern local hyperthermia treatment completely systemic [61] [62] , reaching bystander and abscopal effects [63] [64] , by production of the immune-stimulating character for both the innate and adaptive immune system [65] , and turning the oncologic hyperthermia to a complex immune-therapy, attacking the far-distant metastases, named “immunotherm” therapy [66] .

2. Dosing of Hyperthermia

Evaluating the success of hyperthermia’s definitive dose is mandatory. Experts agree that the reliable dosing determines the future of oncologic hyperthermia [66] .

The heating process is an energy transfer to the target. This energy could increase the temperature and could make many other accompanied effects [67] [68] . Naturally, the medical expectation is definitely making chan- ges in the target, killing the malignant cells in various ways. The cell killing obviously demand senergy, which is delivered by the electromagnetic or mechanical (ultrasound) forms in most of the hyperthermia methods. The temperature is the average energy that is provided to the target. When the target is large, it needs more heat- energy to reach the same temperature than the small target. This is why we introduced the absorbed energy for unit volume or unit mass, as we did in case of ionizing radiation: J/kg (= Gy). This is an exact dose that we can use when we know the absorbed energy. However, the target is not isolated thermally, so it loses a lot of heat- energy by heat-conduction to the neighbors, and by the intensive heat exchange of the blood-flow. Also, the problematic point is the energy-delivery path. The energy is transported through the non-targeted volumes from the surface to the target, losing a large amount of the energy out of the target. This is not only wasted energy, but also a source of the thermal toxicity. The surface cooling makes the next complication, which sinks a lot of forwarded energy to the cooler. These points request a local measurement in the target. What to measure? We could measure the absorbed energy; or easier to measure, the temperature there, which we suppose has monotonic calibration to the energy itself. So the temperature has a role of some kind of dosing by calibration to absorbed energy; also, it is a safety parameter with the help of which we can be sure that the target does not have too toxic energy-exposition for the healthy tissue.

When the energy-absorption and the energy-distribution is heterogenic, and has fluctuations in the volume, then the temperature measurement also has fluctuations, and we have to wait while the temperature is “equalized” to become a steady-state condition, where the temperature can be regarded as constant. This process emphasizes the time-parameter as important as the temperature itself in two ways: 1) Time duration and energy delivery are linearly proportional; 2) Longer time spreads the energy, approaches equilibrium mostly by non-linear way. Taking into consideration these parameters, complications grow with the heterogeneity of the absorbing target. For example, in case of the nanoheating an extremely huge energy density is absorbed in a very small volume, and the main heating effect is based on their heat-conductive environment.

For the proper dose definition, a well-defined goal (the expected effect) has to be described. The dose in this case must be derived from various model systems (in silico, in vitro and in vivo), while clinicians apply this method at the patient’s bed. Unfortunately, the two approaches (experimental and medical) do not meet organically. One of the multiple reasons of deviations is that the model systems are mostly treated by monotherapies, while medical practice predominantly uses the oncologic hyperthermia as a complementary method together with one or more “gold standards”. On the other hand, the biological variability is much more in the real treatment on humans than in the models. During experimental trials we can investigate the basic (mainly molecular) mechanisms of hyperthermia, while the clinical applications are sharply connected to the various physiological reactions, like the blood-flow, lymph-transports, and in consequence, the drug-delivery of chemotherapies, the oxygenation for radio-sensitizing, etc. Some special functional parameters of the treated organ are used for control of the in situ actions, but these methods are not at all standard enough to be used for dosing. The control of this type gives important safety information to avoid or minimize the adverse reactions, but not appropriate to use as dose. Some technical, mainly thermal parameters are also used to control the processes without proper dose. For example, the highest temperature achieved is used [69] , or the total heat-energy is counted [70] , or the time of exposure is chosen for characterization [71] . These methods are technically precise, but they are not enough to characterize the biological response. While dosing we have to consider the complex physiological response of the target, which drastically modifies the absorbed energy and the temperature.

The concept of oncological doses is based on the maximal tolerable dose determined by dose escalation, measured in specific concentration of the drug (such as mg/m2), or specific energy of the radiation (such as Gy = J/kg). The efficacy is measured mostly by the local control, the response rate, which is measured most frequently off-situ with imaging techniques. When the efficacy is measured on the survival or other long-time realization of the development of the disease (much longer than the treatment is active), it would be too complex to verify it as the dose, due to the fact that the interim control during the treatment process is mandatory.

The definition of the real dose must be based on the effect, which we expect by the application of the proper dose. The dose of an action is measured by the final effect, which is made by a “tool” (such as drug concentration, radiation, temperature, etc.). The effect in our case is the selective distortion of the cancer cells. The definition of the distortion is the cell-death of malignant cells without harm (or less harm) in their healthy counterpart. There are various possible ways of cell-killing in a wide range from necrosis to apoptosis, or autophagy, having many variations of their “mixture”, called necroptosis, aptonecrosis, etc. [72] . These processes could happen on avery different time-scale, depending on their regulatory pathways; and the necrotic cell-death could be complexly regulated [73] .

The inherent problem of dosing is that the quantity of the final result of the action of the tool is defined by the tool itself (concentration, intensity, etc.). The way from the action to the result considered standard is too rough―an oversimplified assumption in high complexity systems with high bio-variability.

The majority of physicians who are using heating techniques have a common view about the cellular damage, stating its thermal behavior. However, the same forwarded energy exposition with identical energy-flow [W/m2] can cause different energy-absorptions [74] depending on the given conditions [75] [76] , the actual organ [77] , and also modified by the actual frequency [78] .

The simplest thermodynamical way is of course to measure the temperature, and by the higher kinetic energy that surmounts the energy barrier of the actual reactions. However, the heating differs in the target, even microscopically, and the same temperature acts differently for the large complex chemical machinery of the cell. If the temperature is high enough it acts for most of the possible reactions, irrespective of their state or actual needs. Due to the overall excitations the desired selection vanishes. Energizing by temperature does not take into account the individual energy barriers of the various reactions or reaction cascades; it is an overall driving force to react. It defines a certain probability of the effect of individual reactants. When the given reaction has the Ea barrier height (activation energy), the reaction rate k (probability of overpassing the barrier) is proportional to the exponential function of the ratio of the height of the barrier and the energy represented by the temperature that can be described by the Arrhenius law

(1)

where RG is a universal gas-constant (RG ≈ 8.3 [J/K/mol]). The excitation of the particles is temperature dependent. The actual pre-exponential factor (A) and the Ea activation energy have to be determined on an experimental basis. The general basis of the chemical reaction-kinetics with temperature is the Arrhenius law. The ATP synthesis is temperature dependent, also following the Arrhenius law [79] .

3. Sapareto-Dewey’s Approximation of Dose of Thermal Damage

The theoretical model of the criteria of the cell-death is described by the

(2)

simple reaction equation, which means the living cell N turns to (number of) dead one D by reaction rate χ. This could be modelled by autolysis, having the linear decay equation

(3)

where is the concentration of the living cells in t-time. The χ reaction rate could be given by the Arrhenius Equation (1), so

(4)

The thermo-dynamical measurement of necrotic hyperthermia treatments in-vitro accurately fits the Arrhenius plot [80] [81] . The relevant reaction rate could be calculated from the slope of the survival rate by treatment time.

Introducing the damage function

(5)

It follows

(6)

Knowing the relevant parameters, the thermal dose is calculable from this equation [82] , as

(7)

When the chemical or structural properties change, the value of Ec changes, too. Due to the linearity of the Arrhenius plot and its reverse time dimension of χ, we introduce its reciprocal value as time constant [83] as. When we have the ratio of two different time-constants as where T1 and T2 are close to each other, then

(8)

The thermal damage has a characteristic graph in dependence of 1/T as usually plotted by the Arrhenius conditions

(9)

In case of components of living materials (like proteins, cells, tissues) the ln(A) is approximated from the experiments by linear dependence

(10)

where ξ = 0.38 and ζ = −9.36 [84] , or in other publication ξ = 3.832 and ζ = 10.042 [84] [85] .

So the characteristic time is

(11)

Comparing the thermal cell damages to each other, we choose treatments made on T1 temperature by t1, time and other one on T2 temperature by t2 duration. According to Equation (7) the thermal damage functions are

(12)

We consider two treatments thermally equal, when their thermal damages are equal. We can choose equivalent times using Equation (12), when we would like to compare the effects of and time-temper- ature pairs. Consequently, with the approximation in Equation (8), we get

(13)

If the reference-time and corresponding temperatures are tr and Tr respectively, then the iso-effective equivalent time, which is necessary at the T-temperature would be

(14)

When we choose as reference time at temperature, we get a simple equation for isodose with pair when we use in actual treatment, according to Equation (13)

(15)

where. In this way, the equivalent time depends on the relative temperature difference by a power-law

(16)

In consequence of this tr reference choice, we can introduce a dose unit; when the heating is time-dependent, summarizing all the intervals regarded as constant temperature, using steady-state approximation. This cumulative value as “cumulative equivalent minutes” (CEM) is in steady-state

(17)

where ti are the times when the corresponding T(ti) regarded as constant. In a continuous change of the temperature, the sum is transformed to an integral

(18)

where the treatment time t is conventionally measured in minutes. The general equivalent time CEM in Equation (18) does not fix the reference for one definite cell-death, it is general for all the cases when the Arrhenius process is valid.

When the activation energy is constant, the Arrhenius plot is linear by the reciprocal of the temperature. However, when a drastic new reaction or phase transition happens the activation energy changes and the derivative of the Arrhenius curve is modified by the thermal load with increasing temperature. In this case, the anyway linear dependence of the logarithm of reaction-rate to 1/T breaks, the slope of the line changes, and a kink occurs on the Arrhenius plot [83] . When the transition is irreversible, the modified activation energy remains characteristic in the temperatures, when the curve had another derivative anyway, establishing the basic of the step-down heating [80] . In consequence of the kinked sequentially linear dependence the temperature of the time-constant could also be easily plotted [83] . When one of the conditions of the 273 & or &, [where Tk is the temperature (in Celsius units) T1-where the kink (Ea1 ↔ Ea2 transition) occurs] relations are valid, we have

(19)

The step-function form of Ψ is consequence of the kink measured in the Arrhenius plot at temperature Tk, [K]. Classic hyperthermia had chosen for standardization this t43 point. Conventionally, the value of Ψ is noted R in this special necrosis-based standardization. By this choice, the reference point was definitely fixed as the necrotic threshold in the special in vitro experiments [86] . In most cases of thermal necrotic cell-death, approved mostly in in vitro experiments Tk = 316 K = 43˚C and Ψ1 = 0.5, Ψ2 = 0.25 [80] , showing there is as large reduction as almost 1/3 of the activation-energy above this point [87] (Ψ denoted with R in this special case). The in vivo model-experiments are near to this breaking point [88] , due to the fact that it is connected to a lipid-phase transition in a cell membrane. The reference values are connected tonecrosisat T2 = 43˚C, made during a treatment-time t43. The dose of the actual treatment refers on the equivalent time of the treatment on other T temperature (denoted by CEM43˚C) [89] . It could be calculated as

(20)

which implies Ea(<43˚C) = 273 kcal/mol and Ea(≥43˚C) = 138 kcal/mol. The kink temperature of the Arrhenius plot could vary by samples, and complementary or pre-treatments [90] . The most likely effect causing the kink is well to the believed lipid phase transition observed around 42.5˚C [83] , but other effects modifying other essential proteins are also possible. The choice of the 43˚C for the breakpoint was supported by the value of the blood-flow contraction threshold, which is at about 42.5˚C [91] , and also, it corresponds.

However, according to the various experiments below and above the breakpoint temperature, the activation energies do not fit to the fixed R values. One well-accepted result [92] shows Ea1 = 365 kcal/mol ≈ 1527 kJ/mol below this point, while above Ea2 = 148 kcal/mol ≈ 620 kJ/mol. These values implicate R(<43˚C) = 0.159; R(≥43˚C) = 0.474, instead of R(<43˚C) = 0.25; R(≥43˚C) = 0.5, respectively. The error is significantly robust (~36%), below the breakpoint, showing that the non-necrotic damage cannot be described accurately with the classic CEM43˚C dose.

4. Generalized Dose

The Arrhenius picture is useful for various heating induced changes in tissues and in physiological phenomena [86] . The measured parameters in these biologically quite high temperatures are remarkably higher than those of the simple chemical processes.

The cell-death could be performed by various parallel ways. Keeping the standard Arrhenius-based Henrique-Moritz model [93] , we assume that all the cell-damages are necrotic, and could be modelled by parallel, dominantly irreversible chemical reactions. However, there is a robust cellular reparation mechanism, which blocks the cell-death in part of the cells. These cells are able to recover their damaged proteins by reparation (mainly HSP chaperones are active in this effect), and survive the thermo-electro attack. Even a part of these cells could become heat-resistant [94] .

There are various kinds of the cell-deaths, having a huge variation of the activation energy, so the linear Arrhenius plot with one single straight line and one breakpoint on it is too idealistic [95] . In most of the cases, the thermal effects over the threshold are non-reversible. Such an obvious case is the burning (temperature induced necrosis), which is sensed before it happens, the threshold for discomfort is 10 - 100 times lower than a thermal dose for necrosis [96] . There is often not enough oxygen to accommodate the increased metabolic rate, resulting in hypoxia [97] and anaerobe metabolism, producing lactate [98] and cell destruction by acidosis. As a consequence, the concept of the irreversible phase-transition was developed and the treatment protocol became a step-down heating [99] . This method is supposed to have an irreversible phase transition at 42.5˚C, and after first overcoming this threshold, the treatment could be continued of a lower temperature, because the actual distortion (lowering the activation energy) is effective from that moment.

However, the definite phase-transition temperature (Arrhenius kink) changes by the chemotherapies [90] , and it strongly depends on the heating dynamism (slow and rapid) [100] and on the pre-heating conditions as well. These facts predict a complex tissue dependent phase-transition (better to tell a chemical reaction); the drug metabolism and the transition dynamism are definitely involved.

The above described dose idea does not cover all cell-damage processes. Ea could vary by the actual effects, having not only a simple, immediate necrosis. In a simple case when the electromagnetic heating is applied, we may suppose a deviation of the effects on at least two different groups; the dominant thermal changes, which depend only on the absorbed energy (SAR) irrespective the source of the energy delivery. Another part of the effect could depend on the mode of how the energy was delivered, that is, the actual electro-magnetic field, which is the source of the interactive forces, could make special effects on the ionic charges and dipoles which are the constructive elements of the biomatter. These effects are thermally induced, but not necessarily thermal. They are behaving at least as phase-transition of first order, having so called “latent heat”. This means that after reaching the transition temperature that value does not change until the transition process is completed. In this interval the temperature will be independent from the pumped in SAR value. In this simplest case, when we divide the cause of the cell-death on the purely thermal and non-thermal but thermally induced components, the parallel reactions could be described as follows

(21)

where A is the cell treated complexly, and are their activated (transition) state, the purely thermal component noted by subscript “t”, while the “non-thermal” with “n”, is the death state of the cell. The is the transition-rate to the active state, while is transition-rate to the repaired state, and is the transition-rate to death.

Note the “non-thermal” component is only apparently not thermal. It well depend on the heat-energy which is needed for the chemical changes. This “latent heat” is energy associated with the energy of phase-change of the substance and it occurs in case of every first-order phase-transition. In case of pure water the latent-heat at melting of ice is 334 kJ/kg, while at the evaporation it is 2260 kJ/kg at 0˚C and 100˚C respectively. During of the absorbing of the “latent heat” the temperature does not change, so it is better to use the statement of “actually non-temperature dependent” [95] instead of the “non-thermal”, because during the absorbance process the tem- perature remains constant. Anyway, all the “non-thermal” components have definite energy-exchange which is thermal in the general meaning of thermodynamics.

Here, the dynamism of the processes is not included, and the time of staying in the actual state has no role. What is probable, however, is that the electric excitation process definitely has a longer time than the thermal one. The cross-effects are also not counted. The processes when one kind of excitation promotes the other one are calculated only by their final death independently from the history of the process itself. We consider that the thermal effects are dominantly necrotic, while the electrical one is dominantly necrotic, and note again that no strict border exists between the processes, or between the thermal and electric excitation. There is a massive appearance of thermally induced electric and electrically induced thermal effects, making the complete process complex. Applying a model of first order parallel reactions, the reaction-kinetic equations are

(22)

Supposing the likely conditions of, and then the is probably stationer, so we get

(23)

From this, the concentration of the cells in activated state is

(24)

With this, we get the following simple reaction-kinetic equation

(25)

Following this method, the second reaction of Equation (21) will be such a simple decay reaction equation

(26)

After these calculations the cell damage could be described by the following irreversible parallel reaction scheme

(27)

which could be described by the following reaction-kinetic equations

(28)

where would be the “apparent” reaction rates. Supposing the initial conditions, we get the solution

(29)

From where the so-called “branching ratio” is

(30)

This means that the concentration ratio of the death-cells depends only on the ratio of the apparent reaction

rates. When the does not depend on the temperature, then the concentration ratio in the parallel reaction

branches is constant, which means in our case that the ration of necrotic (caused by global SAR) and apoptotic cell damage (caused by local SAR) is independent of the temperature. We suppose that the apparent reaction rate also fulfils the Arrhenius law, then

(31)

where Ci is a constant, Eai is the cellular activation energy of i-th components, and R is the universal gas-con- stant (R = 8.314 J/K/mole). Then the consequence is a fixed ratio

(32)

Consequently, the global cell damage described by the first equation of Equation (28) has the following kinetic equation

(33)

where we used the branching ratio from Equation (30). Introducing the damage function as

(34)

where t0 is the starting time of the process (t0 = 0) and the a consequence of Equation (33) we get

(35)

With this, the damage function is calculable

(36)

where is the thermal damage, and is the “non-thermal” (but anyway thermally induced) damage function. Consequently, the resultant damage function by means of the branching ratio could be expressed by the thermal damage function

(37)

On the above basis we introduce the generalized iso-effect of the thermal dose. Treatments could be compared by their efficacy, which has not only thermal, but “non-thermal” components, too. In this case

(38)

where the situation corresponds to the pure thermal case described in Equations (12) and (13) if the points of 1 and 2 are close to each other, and the coefficients of the exponential function are nearly equal. Consequently, the isodose principle is identical with thermal despite of the additional (synergistic) effect of thermally induced, but not directly temperature dependent factors.

According to Equation (38) and using the condition of the equivalence described above, the functions of thermal damage at pair of values compared to a reference pair are

(39)

In a cumulative approach, we get, similarly to Equation (18)

(40)

where Ψ is a function determined by the Arrhenius law

(41)

When Ea and An are constants and the difference is not too large, then

(42)

where, Qgen is a generalized pre-factor

(43)

The general equivalent time CEMgen in Equation (40) does not fix the reference for one definite cell-death or for definite duration of the process. The An/Ar ratio could be very high in special processes (like electroporation [101] An/Ar ≈ 77). The cell-destroying process could be guided by very little temperature change with extra huge thermal gradient on the plasma-membrane [102] , which simply describes the full process “non-thermal”. These effects are mostly induced by the frequency-dependent non-homogeneities in the distribution of induced and absorbed RF E-field and specific absorption rate at cellular level [2] .

5. Modulated Electro-Hyperthermia (Oncothermia)

Modulated electro-hyperthermia (oncothermia, OTM) is devoted to solve the currentproblems [95] [103] . Oncothermia is a thermal process [104] . It uses nanoparticles (natural nanoclusters) as energy absorbers. These naturally presented nanoparticles (membrane clusters, rafts [105] ) are non-artificial, well-studied nanoclusters in the membranes of the cells. OTM selectively targets these nanoclusters [106] . The selection mechanism is based on multiple effects [107] that cause effective changes in the targeted cell and in its immediate vicinity [108] . The technical details are described elsewhere [14] . Their energy absorption induces heat in the membrane. The heat- energy spreads all over the tumor and heats it up in an effective and well oriented way. Various complex signal pathways of transduction networks of the selectively targeted malignant cells are excited by the heated rafts [109] , including the massive Ca2+ influx into the cytoplasm.

The apoptotic damage usually takes a longer time to be performed. Its usual visibility takes at least 24 h, and could not be globally considered as simple Arrhenius plot, because this process is much more complex by its chemical changes. The multiple processes that are needed for apoptosis [110] contain a cell shrinking, nucleus condensing (pyknosis, time: 4 - 8 h), blebs on plasma-membrane, nucleus fragmenting (karyorrhexis, time: 10 - 24 h), and the appearance of apoptotic bodies (phagocyte engulf apoptotic bodies, time: 48 - 72 h). The phenomenon of “no return” is the release of Cytochrome C [111] , which happens at least 4 h after the start of apoptosis with the help of outer signal pathway (oncothermia cell killing) [111] . We know it from the measurements, that the Arrhenius plot is linear (no kink) below 42˚C, so oncothermia has to use this line for dose. However, the Arrhenius curve is mostly measured in vitro, and the necrotic cell-death was considered as the dominant thermal effect. The Arrhenius plot for thermally activated non-necrotic cell-killing has to describe the thermal behavior of the “point of no return” where the process becomes irreversible and the cell is “committed to die” [111] . This is the BAX pore formation on mitochondria and the release of Cytochrome C. We have to choose a parameter characterizing a process of the non-necrotic cell-killing.

In case of oncothermia the physical character of the action is the electric field. This applied field increases the temperature by:

・ global absorption (general SAR), which is the overall absorbed energy of the target divided by its mass, which is selected by impedance differences between the target and the normal tissue [112] uses certain Ca2+ influx and thermolysis [111] .

This is because the thermal activation of transient receptor potentials (TRPs) has a crucial role in the apoptotic cell-death, caused by modulated electric field [111] . However, we can assume that the synergy of the thermal and electric effect and the induced damage function is proportional with each other. This was experimentally proven at two temperature points (38˚C and 42˚C) [113] . Unfortunately, the exact cell-destruction mechanisms are not known in both classical hyperthermia and oncothermia cases, but the possible proportion can lead us to the oncothermia dose.

In cases of the modulated electrohyperthermia studies, the concentrations of the dead cells by thermal damage is [At], and the concentration of the dead cells made by electric damage is [Ae], then the branching ratio by the experiments [112] is

(44)

Using the Equations (37) and (44) we get

(45)

The combined thermal and electric effects have three times more cell distortion than the thermal has alone.

The selective and effective cell destruction makes a new kind of hyperthermia in oncology possible. This new treatment could use the definite electric and thermal in homogeneities of the tumor to kill effectively the cancer-cells without hurting their healthy vicinity. This selective SAR process causes the strong synergy between the direct thermal and indirect thermal (special electric field absorption) processes [113] . The thermal effect in this case is different than in the classical hyperthermia heating. In the conventional approach the goal is the homogeneous temperature all over the tumor, while according to the cellular selectivity, oncothermia is not based on the homogeneous heating. The specific absorption rate (SAR) is derived by the specialties of the cancer-cells allowing to find them, and absorbed the SAR in that place. Due to this process the prospects of oncothermia is huge even in those tumor cases, which are generally contraindicated for the overall heating of the mass; like brain, eye, or other sensitive organs or inoperable cases. These sensitive places are treated with success with oncothermia [95] [114] and even the bleeding tumors and the inflammatory cases can also be successfully treated with the method [115] .

6. Conclusion

Generalized dose has been introduced for the non-homogeneous temperature distribution including the electric field absorption as a component of SAR. The generalization is discussed in the frame of thermal effects applied in the Arrhenius thermal law. The dosing and efficacy of modulated electro-hyperthermia (oncothermia) are described, and due to the non-homogeneous heating and selective targeting it is about three times higher than that of the homogeneous classical mass-heating.

Cite this paper

GyulaVincze,OliverSzasz,AndrasSzasz, (2015) Generalization of the Thermal Dose of Hyperthermia in Oncology. Open Journal of Biophysics,05,97-114. doi: 10.4236/ojbiphy.2015.54009
