Research on Material Irradiation in HANARO
Man-Soon Cho*, Kee-Nam Choo, Seoung-Woo Yang, Sang-Jun Park
Department of Research Reactor Utilization, Korea Atomic Energy Research Institute, Daejeon, South Kor ea
Received 12 June 2014
Abstract
HANARO (High-Flux Advanced Neutron Application Reactor) is a 30MWth multi-purpose research
reactor generating a very high neutron flux for scientific and technical applications. Since its ini-
tial criticality in Feb. 1995, it has worked as a national neutron source for neutron beam research,
RI production and related research, material and fuel irradiation research, and neutron transmu-
tation doping. The installation of a cold neutron source and related beam instrument makes
HANARO serve as a regional source for beam research as well. As Korea is developing nuclear
power systems and fuels, irradiation research is a main utilization subject in HANARO, and irradi-
ation facilities have been actively utilized for various nuclear fuel and material irradiation tests
requested by users from research institutes, universities, and industries. Most of the irradiation
tests were related to the R & D relevant to the ageing management and safety evaluation of the
present nuclear power reactors. Korea is conducting R & D programs relevant to new nuclear sys-
tems including a research reactor, System-integrated Modular Advanced Reactor (SMART), and
future nuclear systems such as a very high temperature reactor system (VHTR) and sodium cooled
fast reactor system (SFR). To effectively support the R&D for new nuclear systems, advanced ir-
radiation technologies such as high-temperature irradiation, instrumentation, and long-term ir-
radiation are being developed. In addition, research on the irradiation characteristics of su-
per-conductor materials and new chemical materials is being conducted as a part of fundamental
researc h.
Keywords
HANARO, Neut ron , Flux, I rr adi ati o n, SMART, VHTR, SFR
1. Introduction
HANARO (High-flux Advanced Neutron Application Reactor) was designed to obtain a high density neutron
flux (5 × 1014 n/cm2 sec) with a relatively low thermal output (30 MW) to be utilized in various studies such as
fuel and material tests, radioisotope production, neutron activation analysis, neutron beam utilization, neutron
tra nsmutation doping, etc. It was on Feb. 8, 1995 that HANARO, designed and constructed by Korean engineers,
achieved first criticality. HANARO is a typical multipurpose research reactor using all three kinds of neutrons.
Though it cannot be equivalent to a reactor using only one or two kinds of neutrons, HANARO provides most
*
Corresponding author.

M.-S. Cho et al.
856
areas of its utilization capabilities for global competition
In HANARO, the inner core has 28 fuel sites and 3 test sites. The 3 test sites of CT, IR1 and IR2, are hex-
agonal in shape and are used for irradiation of the capsules, FTL (Fuel Test Loop), and RI (Radioisotope) pro-
duction. The outer core consists of 4 fuel sites and 4 test sites (OR1 to 8), which are embedded in the reflector
tank. In addition, there are several vertical test holes such as LH (Large Hole), HTS (Hydraulic Transfer Sys-
tem), NTD (Neutron Transmutation Doping) and IP (Irradiation Position) in the reflector region for the irradia-
tion tests, RI production and NTD, as shown in Figure 1.
2. Irradiation Capsules in HANARO
Irradiation tests of the materials at HANARO have been performed usually at temperatures of 250˚C - 400˚C, at
which the RPV materials of PWR reactors are being operated up to the present. They have been performed using
a standard capsule. As the reactors planned in the Gen-IV program will be operated at high temperature and un-
der high neutron flux, the requirements for the irradiation of materials at high temperature and flux are recently
being gradually increased. The operating temperatures of the VHTR and SFR are expected to be 1000˚C and
550˚C, respectively [1], which are much higher than the irradiation temperatures of material capsules tested at
HANARO up to recently. On the other hand, KAERI is participating in the development of new research reac-
tors, i.e., the Ki-Jang of Korea and the JRTR of Jordan. The materials used for the reflector of research reactors
are graphite, beryllium, and Zircaloy. They are operating at low temperature of less than 100˚C, and thus irradi-
ation data at low temperature are necessary. The capsules in HANARO have been developed according to the
various temperature requirements. They are classified as a standard capsule, a high-temperature capsule, and a
low-temperature capsule, which are used respectively for irradiation at temperatures of 200˚C - 500˚C, lower
than 100˚C, and higher than 700˚C. In addition, the various irradiation facilities such as a rabbit, small non- in-
strumented capsule, loop, and target for RI production are used at HANARO. Analyses for the reactivity effect,
neutron flux, and gamma heating necessary for capsule design are performed mainly by the common MCNP
code. The irradiation temperature is analyzed using the GENGTC and ANSYS codes.
2.1. Standard Capsule
The standard capsules are mostly used for irradiation at temperatures of 250˚C - 400˚C. The development of the
standard material capsule and the related technology started in 1995, and it was first irradiated in HANARO in
1998. Now, it has an important role in the integrity evaluation of the reactor core materials and the development
of new materials through the irradiation tests of specimens such as RPV, reactor core, pressure tube, fuel clad-
ding of PWR, and high-technology materials. The standard capsule, which is usually called an instrumented
material capsule, is shown in Figure 2. It is cylindrical in shape, and its main-body is about 60 mm in diameter
and 870 mm in length. It consists of three parts connected to each other: a protection tube, a guide tube, and the
main body. The main body including the specimens and instruments is a cylindrical shaped stainless steel tube.
Figure 1. HANARO core.

M.-S. Cho et al.
857
Figure 2. Standard capsule, parts and specimens.
2.2. Low-Temperature Capsule
The concept of a low-temperature capsule is direct contact with the coolant to cool the specimen down. The
capsule makes the reactor coolant pass through the bottom hole, as shown in Figure 3, which is different with
the configuration of a standard capsule filled with He in a sealed atmosphere.
The low-temperature capsule is used for irradiation of the reflector material in a research reactor, such as
graphite, beryllium, and zircaloy-4, because the research reactors are usually operating at low temperature
(<100˚C). The results will be utilized for an acquisition of the irradiation data necessary for the design of re-
search reactors such as JRTR and Ki-j ang.
2.3. High-Temperature Capsule
The high-temperature irradiation capsule which will be used for high-temperature irradiation of up to 1000˚C
has been developed as a concept with double thermal media, as shown in Figure 4. Because the Al thermal me-
dia used in a standard capsule might melt at high temperature, other materials enduring high temperature such as
Ti or Zr should be used as the inner thermal media holding specimen. This capsule is being developed to use for
irradiation of VHTR material.
2.4. Others
In addition, various neutron irradiation facilities such as a rabbit, no n-in stru me nted capsule, target for radio iso-
tope production, and fuel capsules have been developed at HANARO. The rabbit and target were originally de-
signed for NAA and RI production, but they can also be used for irradiation of fuel and material.
Non-instrumented capsules have been used for a test in which the irradiation temperatures are required to be
in a large range or for the irradiation of nuclear fuel. It is typically 1 m in length and 56 mm in diameter. It was
used mainly for the irradiation of DUPIC, Advanced PWR, and CANDU fuels. It is currently being used for the
irradiation of concrete material, SPND, and U-moly, VHTR and SFR fuel.
3. Recent Utilization of Irradiation Capsules
As the integrity assessment and lifetime extension of NPP are posing a big social problem around the world after
Fukushima accident, the irradiation data for structural materials and nuclear fuels for NPP are indispensable and
some are urgently required in Korea. Because the future nuclear energy systems are being developed as a me-
thod to get the new energy source worldwide and Korea participates in development of SFR and VHTR, the ir-
radiation capabilities are emerging as an important issue at the present time. Recently, the irradiation test for re-
search reactor materials has been finished, and that for RPV materials was performed in HANARO. And the ir-
radiation tests for VHTR and SFR fuel are being carried out as well as fusion reactor materials for development
of the future nuclear systems. In addition, the instruments such LVDT and SPND are being developed. The re-
cent irradiation status is described simply as below.
3.1. High-Dose Irradiation of RPV Steel for Currently Operation PWR
The continued utilization of nuclear energy systems for worldwide base load electricity offers a number of ma-
terials research challenges. One of the major degradation issues for reactor pressure vessel (RPV) steels is em-
brittlement associated with hardening from radiation induced solute-defect clusters. However, the effects of
R-CT
tensile

M.-S. Cho et al.
858
Figure 3. Low-temperature capsule.
Figure 4. High -temperature capsule.
high-dose, long-term operation lifetimes and irradiation flux on hardening and embrittlement of RPV steel are
now well-known worldwide. It is needed to obtain data from domestic RPV steel after high-dose irradiation for
te potential extension of reactor operation licensing of nuclear power plants beyond their initial term. The spe-
cimens are the archive material of SA 508-Cr.3 RPV steel. 58 specimens for tension, fracture toughness and
Charpy impact testing were inserted in the capsule and irradiated at fluence up to 5.51 × 1019 (n/ cm2) (E > 1.0
MeV). The irradiation temperature was controlled at 290˚C ± 10˚C. The tension testing was conducted in the
range of 25˚C - 371˚C with strain rate of 5.6 × 10−4/s, and the result is shown in Figure 5 [2]. The loading rate
of the fracture toughness test was 0.15 mm/min that corresponds to 1 MPa m/s. The test results for irradiated
RPV steel will be compared with the results for pre-irradiated RPV steel.
3.2. Irradiation of RR (Research Reactor) Materials
Recently, Korea has much concern for development and export of RR because it succeeded to export a RR to
Jordan and began to construct a new RR in Ki-jang which is located in the southern part. However, the irradia-
tion data for core structural materials such as graphite [3], beryllium and zircaloy-4 are very difficult to find, and
so they are being the important issues for design and license of RR. Especially, it is very difficult to obtain the
irradiation data at the low temperature below 100˚C, which is operating condition of RR. Accordingly, produc-
ing the irradiation data for RR materials by ourselves is required at this time. The irradiation tests were finished
in the early of 2014, some of the results were obtained. Figure 6 shows the specimen temperatures during irrad-
iation. The irradiation growth was measured in the hot cell. For Be, the results are almost same with S20F and
EHP56. The irradiation growths of Zr-4 are almost same in the rolling and tangential directions. The hardness
values increased slightly after irradiation.
3.3. Irradiation of Reinforced Concrete
Reinforced concrete (RC) is a composite material in which the concrete’s relative low tensile strength and duc-
tility is counteracted by steel bars as reinforcement in tensile regions. It is commonly used as a biological shield
and as a load carrying support for a reactor vessel and, if any, changes in the mechanical properties can be par-
ticular significant for long-term irradiation. This study aims to investigate the response of a beam member in the
RC design for long-term irradiation that RC supporting the reactor vessel may experience [4]. The RC structure
close to the reactor vessel was considered as the most critical in estimating that the total fluence for 40 years

M.-S. Cho et al.
859
Figure 5 . Tensile strength of RPV steel [2].
Figure 6 . Irradiation of RR materials .
becomes about 1014 to 1018 n/ cm2. The moment-curvature response of an RC beam was investigated with the
maximum neutron fluence up to 1019 n/c m2 and it shows twice the increase in ultimate strength, which is mainly
contributed from the increased yield stress of mild steel. The RC beam response became so brittle that it may
fail without large deformation as a warning. The same observation can be equally applied to other RC designs
such as the column, slab, and foundation. Furthermore, the current investigation will be extended to a structural
integrity evaluation of aging NPPs.
3.4. Irradiation the Mini Plate Type U-7Mo Fuel for Research Reactor
U-Mo particle dispersion in an aluminum matrix, termed as U-Mo/Al hereafter, has been under development for
the use of high power research and test reactors because of its potential for high U-density. Interaction layer
growth and occasional porosity formation in the matrix, however, has been hampering its qualification [5]. An
excessive interaction layer growth and pore formation in the interaction layers observed in this fuel. Perfor-
mance of the plate type U-7 wt% Mo dispersed in an Al-5 wt% Si alloy matrix, is being investigated through ir-
radiation tests in HANARO at KAERI. These tests will be performed three times as the burn-up rate of 45%, 65%
0 2 4 6 810 12 14 16 18 20
0
100
200
300
400
500
600
700
Hanul-3 RPV Steel, 288oC
(5.5x1019 n/cm2, E>1MeV)
Pre-irradiated
Post-irradiated
Engineering Stress (MPa)
Engineering Strain (%)

M.-S. Cho et al.
860
and 85% respectively. Currently, the 1st mini-plate type of U-Mo fuel is being irradiated for 5 months in
HANARO. Post-irradiation metallographic features and swelling etc. will be investigated after irradiation.
3.5. Irradiation of Coated Particle Fuel
TRISO (tri-structural isotropic) coated particle fuel has been studied extensively around the world. It consists of
a microspheric UO2 fuel kernel surrounded by four coated layers; buffer, IPyC (inner pyrolytic carbon), SiC and
OPyC (outer pyrolytic carbon). Development of fuel is being progressed favorably for use in the VHTR which
will be developed in Korea. The first irradiation test of the coated particle fuel has been recently finished. The
capsule was loaded in OR5 hole in HANARO core, which has a nominal fast neutron flux of 1.2 - 1.5 × 1013
n/cm2 s and a thermal neutron flux 2.0 - 2.5 × 1014 n/cm2 s.
3.6. Irradiation of Si and SiC etc.
The basic researches for Si and Sic etc. are proceeding mainly by professors at universities. The microwave
losses of single crystalline Si and 4H-SiC are being studied because it is one of the most important physical pa-
rameters with regard to the applicability of microwave devices. The loss tangent (tangentδ) of 4H-SiC appeared
to increase significantly when the specimen was irradiated with thermal neutrons [6]. On the other hand, SiC has
attracted interests in radiation research due to the potential to be used in devices operating in high power ranges
and high temperatures space application as well as neutron detectors. These applications may involve the inte-
gration of semiconductor devices into satellite systems in earth orbit, so as to operate for years in a radiation en-
vironment at widely varying temperatures. After neutron irradiation of SiC, a slight positive shift in threshold
voltage shift has been observed, which is attributed to charge damages in the SiC layer. In addition, the im-
provement of critical current of superconducting material is important for the application. It can be achieved by
forming the nano-size defect working as a flux pinning center inside superconductor. The nano-size defect can
be effectively formed by using neutron irradiation in HANARO. Figure 7 shows change of current density of
MgB2 due to irradiation.
3.7. Statistics for Irradiation Samples and Users
The national research and development program on nuclear technology in Korea requires the irradiation tests of
various materials at HANARO. The main activities of the capsule utilization programs are focused on the
in-reactor material tests, safety-related research, and fundamental material research. 11,000 specimens from re-
search institutes, nuclear industry companies, and universities have been irradiated at HANARO for 122,000
hours using capsules and rabbit irradiation systems since 1995. Figure 8 shows the increasing trends of the ir-
radiation specimens and users.
Figure 7. Change of current density.
1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.05.5
10
0
10
1
10
2
10
3
10
4
10
5
Current density (A/cm
2
)
Applied magnetic field (T)
MgB
2
neutron irradiated - 5K
MgB
2
- 5K
MgB
2
neutron irradiated - 20K
MgB
2
- 20K

M.-S. Cho et al.
861
Figure 8. Irradiation samples and users in HANARO.
4. Conclusion
Korea is conducting R & D programs relevant to new nuclear systems including a research reactor, future nuc-
lear systems such as a very high temperature reactor system (VHTR) and sodium cooled fast reactor system
(SFR) and fusion reactor system. In addition, research on the irradiation characteristics of super-conductor ma-
terials and new chemical materials is being conducted as a part of fundamental research. Irradiation tests in
HANARO are mostly related to the R & D relevant to the ageing management and safety evaluation of the
present nuclear power reactors and develop ment of the future nuclear system and production of design data of
research reactor. The HANARO irradiation capsule system has been developed and actively utilized for the ir-
radiation testin g of fuels and mater ials. The irradiation tests of materials up to the present have been performed
usually at temperatures below 300˚C, at which the RPV of PWR materials is being operated. As the irradiation
tests of the materials and fuels for a Gen-IV nuclear system are recently required and the development of new
research reactors is ongoing in Korea, the capsules for high- and low-temperature irradiation are being devel-
oped at HANARO. The capsules will cover the overall range of temperature from low to high. They will be used
for the irradiation of materials and fuel used in a VHTR, SFR, and newly developed research reactors.
Acknowledgements
This work was supported by the National Research Foundation of Korea (NRF) grant funded by the Korea gov-
ernment (MSIP) (NRF-2013M2A8A 1035822).
References
[1] P ark, J.Y. (2009 ) Possibility of Fusion Applications of Current Materials R＆D for GEN-IV Nuclear Energy System in
KAE R I . Ko rea-Japan Blanket Workshop.
[2] Yoon, J.H., et al. (2014) Characteristics of Domestic Reactor Pressure Vessel Steel after High -Dose Neutron Irradia-
tion. Proceeding of HANARO Symposium.
[3] Lee, Y.M., et al. (2014) A Study on the Irradiated Strength and Stress Evaluation of nuclear Graphite Material. Nuclear
Engineering and Design, 269 , 193-19 9.
[4] William, K., et al. (2013) A Review of the Effects of Radiation on Microstructure and Properties of Concrete Used in
Nuclear Power Plants. US NRC, NUREG/CR-7171.
[5] H of ma n, G.L., et al. (2003) Proceeding of the 2003 RERTR International Meeting, Chicago, 5-10 October 2003.
[6] Jung, H.S., et al. (2014) Microwave Losses of Undoped n-Type Silicon and Undoped 4H-SiC Single Crystals at Cryo-
genic Temperatures. Electronic Materials Letters, 1-9.
